English - 15

EnglishEnglish

3D Basics

Features

Samsung's SSG-5100GB 3D glasses enable you to view
3D images on your 3D TV. The Samsung 3D glasses
communicate with Samsung 3D TVs via the 2.4GHz RF
band.

✎

The Samsung 3D glasses are only compatible with
Samsung D, E, and F series 3D TV's that were
released in 2011, 2012, and 2013. These 3D glasses
cannot be connected to other Bluetooth devices.

Parts

LED Indicator & Power Button

Liquid crystal shutter

Battery Cover

For details on how to attach the glass temples and how
to pair the glasses with the TV, refer to the separate 3D
glasses manual.

Replacing the Battery

If the red LED blinks every two seconds continually,
replace the battery with a new one.

✎

Insert the "+" side of the battery into the side marked
with "+" in the battery compartment.

✎

To check the remaining battery capacity, refer to the
pairing section in this manual.

Pull the battery cover

downward

Open the battery cover

Remove the battery

Replace the battery

Push the battery cover

downward

Close the battery cover

Pairing 3D Active Glasses

✎

What is Pairing? Pairing is the process of connecting
3D glasses and a 3D TV so that the two devices can
exchange data.

✎

Ensure your Samsung TV and 3D glasses are no
farther than 19.5 in (50 cm) apart from each other
while pairing is in progress.

•

Turning the glasses on

Press the power
button briefly. The
green LED is turned
on for 3 seconds.
(Make sure that 3D is
activated on the TV
before using the 3D
glasses.)

•

Turning the glasses off

Press the power button briefly. The red LED is turned
on for 3 seconds.

•

Performing the pairing process

Turn the TV on and let it power up completely. Press
and hold the Power button on the glasses. The green
and the red LEDs blink alternately for 2 seconds.

•

Operating range

2~6m

50cm

Recommended pairing distance

Recommended viewing distance

Recommended viewing distance

2~6m (6.5 to 19.5 ft)

Recommended pairing distance

50 cm or less (19.5 in)

✎

Once the 3D glasses are paired, the remaining
battery capacity is displayed on the TV screen. (This
feature only applies to Samsung F series 3D TVs and
3D glasses that have been available since 2013.)

✎

If you keep trying to pair the glasses and the TV, the
battery level will decrease significantly. However, the
battery level will recover to a certain degree in about
a minute.

3D Active Glasses
