34

D-Link DCS-4603 User Manual

Section 3: Configuration

Video

You may configure up to 3 video profiles with different settings for your camera. Hence, you may set up different profiles for your computer and

mobile display. After making any changes, click the

Save

button to save your changes.

Aspect ratio:

Mode:

Frame size:

Maximum

frame rate:

Video Quality:

Constant bit

rate:

Fixed quality:

Set the aspect ratio of the video to 4:3 standard or 16:9 widescreen. After

changing this setting, click

Save

.

Set the video codec to be used to H.264 or JPEG.

Frame size determines the total capture resolution. You can select different

frame sizes depending on the aspect ratio being used:

•  16:9

1920 x 1080, 1280 x 720, 800 x 448, 640 x 360

•  4:3

2048 x 1536, 1440 x 1080, 1280 x 960, 900 x 720, 800 x 592,

640 x 480

A higher frame rate provides smoother motion for videos and requires

more bandwidth. Lower frame rates will result in stuttering motion and

requires less bandwidth.

This limits the maximum frame rate, which can be combined with the

Fixed

quality

 option to optimize the bandwidth utilization and video quality.

If fixed bandwidth utilization is desired regardless of the video quality,

choose

Constant bit rate

 and select the desired bandwidth. When using

the JPEG codec, you can only select a

Fixed quality

option.

The bps will affect the bit rate of the video recorded by the camera. Higher

bit rates result in higher video quality.

Select the image quality level for the camera to try to maintain. High quality

levels will result in increased bit rates.
