16

 | English

1 609 92A 4A8 | (02.10.2018)

Bosch Power Tools

Guide values for maximum screw tightening torques

Figures given in Nm; calculated from the tensional cross-section; utilization of the yield point: 90% (with friction coefficient
µ

total

 = 0.12). As a control measure, always check the tightening torque with a torque wrench.

Property Classes
according to
DIN 267

Standard Screws/Bolts

High-strength Bolts

3.6

4.6

5.6

4.8

6.6

5.8

6.8

6.9

8.8

10.9

12.9

M6

2.71

3.61

4.52

4.8

5.42

6.02

7.22

8.13

9.7

13.6

16.2

M8

6.57

8.7

11

11.6

13.1

14.6

17.5

19.7

23

33

39

M10

13

17.5

22

23

26

29

35

39

47

65

78

M12

22.6

30

37.6

40

45

50

60

67

80

113

135

M14

36

48

60

65

72

79

95

107

130

180

215

M16

55

73

92

98

110

122

147

165

196

275

330

Tips

Before screwing larger, longer screws into hard materials, it
is advisable to pre-drill a pilot hole with the core diameter of
the thread to approx. 2/3 of the screw length.

Note:

 Ensure that no metal particles enter the power tool.

Recommendations for optimal handling of the battery

Protect the battery against moisture and water.
Only store the battery only within a temperature range of -20
to 50 °C. Do not leave the battery in your car in the summer,
for example.
Occasionally clean the ventilation slots on the battery using a
soft brush that is clean and dry.
A significantly reduced operating time after charging indic-
ates that the battery has deteriorated and must be replaced.
Follow the instructions on correct disposal.

Maintenance and Servicing

Maintenance and cleaning

u

Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.

u

To ensure safe and efficient operation, always keep
the power tool and the ventilation slots clean.

After-sales service and advice on using products

Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. You can find explosion drawings and information on
spare parts at:

www.bosch-pt.com

The Bosch product use advice team will be happy to help you
with any questions about our products and their accessor-
ies.
In all correspondence and spare parts orders, please always
include the 10‑digit article number given on the nameplate
of the product.

Great Britain

Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham Uxbridge
UB 9 5HJ
At

www.bosch-pt.co.uk

 you can order spare parts or ar-

range the collection of a product in need of servicing or re-
pair.
Tel. Service: (0344) 7360109
E-Mail: boschservicecentre@bosch.com

Ireland

Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: (01) 4666700
Fax: (01) 4666888

Australia, New Zealand and Pacific Islands

Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: (01300) 307044
Fax: (01300) 307045
Inside New Zealand:
Phone: (0800) 543353
Fax: (0800) 428570
Outside AU and NZ:
Phone: +61 3 95415555
www.bosch-pt.com.au
www.bosch-pt.co.nz

Republic of South Africa
Customer service

Hotline: (011) 6519600

Gauteng – BSC Service Centre

35 Roper Street, New Centre
Johannesburg
