u

In case of damage and improper use of the battery, va-
pours may be emitted.

Ensure the area is well-ventilated

and seek medical attention should you experience any ad-
verse effects. The vapours may irritate the respiratory
system.

u

Do not open the battery.

There is a risk of short-circuit-

ing.

u

The battery can be damaged by pointed objects such
as nails or screwdrivers or by force applied externally.

An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.

u

Only use the battery with products from the manufac-
turer.

 This is the only way in which you can protect the

battery against dangerous overload.

Protect the battery against heat, e.g.
against continuous intense sunlight, fire,
water, and moisture.

 There is a risk of explo-

sion.

Product Description and
Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.

Please observe the illustrations at the beginning of this oper-
ating manual.

Intended Use

The machine is intended for driving in and loosening screws
and bolts as well as for tightening and loosening nuts within
the respective range of dimension.

Product features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

Tool holder

(2)

Locking sleeve

(3)

Gear selector

(4)

Carrying strap lug

(5)

Battery release button

(6)

Battery

(7)

Rotational direction switch

(8)

On/off switch

(9)

"PowerLight"

(10)

Handle (insulated gripping surface)

(11)

Double bit

A)

(12)

Universal bit holder

A)

(13)

Screwdriver bit

A)

(14)

Application tool (e.g. impact socket)

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical data

Cordless impact screwdriver

GDR 120-LI

GDS 120-LI

Article number

3 601 JF0 0..

3 601 JF0 1..

Rated voltage

V =

12

12

No-load speed

– Setting 1

min

-1

0–1300

0–1300

– Setting 2

min

-1

0–2600

0–2600

Impact rate

– Setting 1

min

-1

0–1900

0–1900

– Setting 2

min

-1

0–3200

0–3200

Maximum torque, hard screwdriving applica-
tion according to ISO 5393

Nm

100

105

Machine screw diameter

mm

M4–M12

M4–M12

Screw diameter max.

mm

8

8

Tool holder

¼" internal hexagon

∎

 3/8"

Weight according to EPTA-Procedure
01:2014

kg

1.1

1.1

Permitted ambient temperature

– during charging

°C

0... +45

0... +45

– during operation

A)

 and during storage

°C

-20... +50

-20... +50

Recommended batteries

GBA 12 V ...

GBA 12 V ...

English |

13
