Changing the Tool (see figure B)

f

Before any work on the machine (e. g.,
maintenance, tool change, etc.) as well as
during transport and storage, set the rota-
tional direction switch to the centre posi-
tion.

Unintentional actuation of the On/Off

switch can lead to injuries.

Inserting

Pull the locking sleeve

3

 forward, push the in-

sert tool to the stop into the tool holder

2

 and

release the locking sleeve

3

 to lock the insert

tool.
Use only screwdriver bits with ball catch

1

(DIN 3126-E6.3). Other screwdriver bits

13

 can

be used with a universal bit holder with ball
catch

12

.

Removing

Pull the locking sleeve

3

 forward and remove the

insert tool.

Operation

Method of Operation

The tool holder

2

 with the tool is driven by an

electric motor via a gear and impact mechanism.
The working procedure is divided into two phas-
es:

Screwing in

 and

tightening

 (impact mechanism

in action).
The impact mechanism is activated as soon as
the screwed connection runs tight and thus load
is put on the motor. In this instance, the impact
mechanism converts the power of the motor to
steady rotary impacts. When loosening screws
or nuts, the process is reversed.

Starting Operation

Inserting the Battery

f

Use only original Bosch lithium ion batter-
ies with the voltage listed on the nameplate
of your power tool.

Using other batteries can

lead to injuries and pose a fire hazard.

Note:

Use of batteries not suitable for the ma-

chine can lead to malfunctions of or cause dam-
age to the power tool.
Set the rotational direction switch

8

 to the cen-

tre position in order to avoid unintentional start-
ing. Insert the charged battery

7

 into the handle

so that it can be felt to engage and faces flush
against the handle.

Reversing the Rotational Direction
(see figure C)

The rotational direction switch

8

 is used to re-

verse the rotational direction of the machine.
However, this is not possible with the On/Off
switch

9

 actuated.

Right rotation:

 For driving in screws and tight-

ening nuts, press the rotational direction switch

8

 through to the left stop.

Left Rotation:

 For loosening and unscrewing

screws and nuts, press the rotational direction
switch

8

 through to the right stop.

Switching On and Off

To

start

 the machine, press the On/Off switch

9

and keep it pressed.
The power light

4

 lights up when the On/Off

switch

9

 is slightly or completely pressed, and

allows the work area to be illuminated when
lighting conditions are insufficient.
To switch off the machine,

release

 the On/Off

switch

9

.

Adjusting the Speed

The speed of the switched on power tool can be
variably adjusted, depending on how far the
On/Off switch

9

 is pressed.

Light pressure on the On/Off switch

9

 results in

a low rotational speed. Further pressure on the
switch results in an increase in speed.
