 English |

17

Bosch Power Tools

2 609 140 699 | (3.12.09)

Protect the battery against heat, e. g.,
against continuous intense sunlight,
fire, water, and moisture.

Danger of

explosion.

f

In case of damage and improper use of the
battery, vapours may be emitted. Provide
for fresh air and seek medical help in case
of complaints.

The vapours can irritate the

respiratory system.

f

Use the battery only in conjunction with
your Bosch power tool.

This measure alone

protects the battery against dangerous over-
load.

f

Use only original Bosch batteries with the
voltage listed on the nameplate of your
power tool.

When using other batteries, e. g.

imitations, reconditioned batteries or other
brands, there is danger of injury as well as
property damage through exploding batter-
ies.

Functional Description

Read all safety warnings and all in-
structions.

Failure to follow the

warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.

While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.

Intended Use

The machine is intended for driving in and loos-
ening screws and bolts as well as for tightening
and loosening nuts within the respective range
of dimension.

Product Features

The numbering of the product features refers to
the illustration of the machine on the graphics
page.

1

Screwdriver bit with ball catch *

2

Tool holder

3

Locking sleeve

4

“Power Light”

5

Fixture for carrying strap

6

Battery unlocking button

7

Battery *

8

Rotational direction switch

9

On/Off switch

10

Battery charge-control indicator

11

Handle (insulated gripping surface)

12

Universal bit holder *

13

Screwdriver bit *

* Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.

Technical Data

Cordless Impact Screw-
driver

GDR 10,8-LI

Professional

Article number

3 601 JA6 9..

Rated voltage

V=

10.8

No-load speed

min

-1

0 – 2 600

Impact rate

min

-1

0 – 3 100

Maximum torque,
hard screwdriving
application accord-
ing to ISO 5393

Nm

105

Bolt size

M4 – M12

Max. screw dia.

mm

8

Tool holder

¼" hexagon

socket

Net weight

kg

0.96

Weight according
to EPTA-Procedure
01/2003

kg

1.0

Technical data determined with battery from delivery
scope.
Please observe the article number on the type plate of
your machine. The trade names of the individual ma-
chines may vary.
