16

 | English

1 609 92A 29F | (21.7.16)

Bosch Power Tools



The battery can be damaged by pointed objects such as
nails or screwdrivers or by force applied externally.

An

internal short circuit can occur and the battery can burn,
smoke, explode or overheat.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for cutting and roughing of metal,
stone and wood materials, plastics, non-ferrous metals and
tiles without the use of water. A specific protection guard
must be used when cutting.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Direction-of-rotation arrow on housing

2

Spindle lock button

3

On/Off switch

4

Battery pack *

5

Battery unlocking button *

6

Battery charge-control indicator

7

Protection guard for grinding

8

Grinder spindle

9

Handle (insulated gripping surface)

10

Protection guard for cutting *

11

Clamping bolt with washer

12

Cutting disc *

13

Hex key

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-3.

Typically the A-weighted noise levels of the product are:
Sound pressure level 75 dB(A); Sound power level 86 dB(A).
Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-3:
Surface grinding (roughing): a

h

= 13.5 m/s

2

, K = 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may signif-
icantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Assembly

Battery Charging

Note:

The battery supplied is partially charged. To ensure full

capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.

The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.

The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.

Grinder

GWS 12V-76

Article number

3 601 JF2 0..

Rated voltage

V=

12

Rated speed

min

-1

19 500

Grinding disc diameter, max.

mm

76

Mounting hole diameter

mm

10

Weight according to EPTA-
Procedure 01:2014

kg

0.70 – 0.90

*

* depending on the battery pack being used

** Limited performance at temperatures < 0 ° C

Permitted ambient temperature
– during charging
– during  operation

**

 and during

storage

° C

° C

0 ... + 45

– 20 ... + 50

Recommended batteries

GBA 12V..

GBA 10,8V..

Recommended chargers

GAL 12.. CV

AL 11.. CV

Grinder

GWS 12V-76

* depending on the battery pack being used

** Limited performance at temperatures < 0 ° C
