Assembly

440558_b

17

ASSEMBLY

CAUTION!

Danger of injury if the machine is incom-

plete!
Incomplete machines can lead to injuries

and damage to the machine!
Do not operate the machine unless it has

been fully assembled.

Scope of supply

Carefully remove the shredder from its packaging

and check the following parts for completeness:

Base with grass catcher
Two transport wheels with wheel caps
Upper  shredder  part  with  cutting  and  motor

unit
Hopper
Assembly bag with screws and tools, instruc-

tions  for  use  with  warranty  card  and  service

station listing.

Mounting the transport wheels

1. Slide the wheel axle (2/1) into the base (2/2).
2. Next,  slide  a  large  10x20x1.5  washer  (2/3)

and the bushing (2/4) onto axle (2/1).

3. Afterwards,  slide  the  transport  wheel  (2/5)

onto the bushing (2/4).

4. Slide the medium 8x20x1.5 washer (2/6) onto

the thread and secure the transport used a M8

nut (2/7).

5. Finally,  press  the  wheel  cap  (2/8)  onto  the

transport wheel (2/5).

6. Assembly  of  all  opposite  transport  wheel  ta-

kes place in the same sequence.

Assembling the upper shredder part with

cutting and motor unit (3)

1. Lift the upper shredder part onto the base and

secure it using M5x35 screws (3/1) and was-

hers 5x10x1.

Assembling the hopper (3)

1. Place the hopper onto the upper shredder part

and secure it using ST 4.2x18 screws (3/2).

STARTUP

Comply with working time regulations in force

in your country.
The extension cable must not cross over hop-

per or ejector.
The  shredder  can  only  be  started  when  the

grass catcher is locked.

Check hopper and feed chute for obstructions

prior to starting the machine.
The  counterplate  (7/2)  is  factory-calibrated

and must not be adjusted during initial start-

up.
Do not use the shredder if you are:

Tired
Unwell
Under  the  influence  of  alcohol,  medici-

nes and drugs

DANGER!

Danger  of  injury  from  damaged  compo-

nents!
Damaged  components  can  lead  to  se-

rious and even fatal injuries!
Before taking into operation, carry out a

visual inspection and check the compo-

nents for function.

WARNING!

Risk of injury due to negligence!
Negligence in handling the machine can

result in serious injuries!
Only  use  the  shredder  on  firm,  level

ground and in a stable setup. Do not tilt

or incline the machine during operation.

OPERATION

Operating time

The machine design supports the S6 (40 %) ope-

rating time. This means that the shredder may be

used  60  %  in  idle  and  40  %  under  load.  For  a

time unit of 10 minutes this means 6 minutes idling

and 4 minutes under load. Continuous operation

is possible under these conditions.

Connecting the mains plug

1. Push  down  the  cable  safety  (4/1)  and  insert

the extension cable (5/1) into the socket of the

shredder.

2. Check secure fit of the extension cable.
3. Next,  connect  the  extension  cable  to  your

mains connection.

Switching on the motor

Normal operation mode:
1. Turn  the  direction  of  rotation  switch  (6/3)  of

the cutting drum to the left (6/1).

2. Next, press the On-switch (6/6).
3. The materials to be shredded are pulled in.
Reverse:
