 English |

13

Bosch Power Tools

F 016 L81 219 | (1.4.15)

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” complies with all applicable
provisions of the directives 2011/65/EU, until
19 April 2016: 2006/95/EC, from 20 April 2016 on:
2014/35/EU, until 19 April 2016: 2004/108/EC, from
20 April 2016 on: 2014/30/EU, 2006/42/EC including their
amendments and is in conformity with the following stand-
ards:
EN 60745-1, EN 60745-2-11 (battery powered product),
EN 60335-1, EN 60335-2-29 (battery charger).

Technical file (2006/42/EC, 2000/14/EC) at:
Bosch Lawn and Garden Ltd., PT-HG/ENS-PA2,
Stowmarket, Suffolk IP14 1EY, England

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
01.04.2015

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-11.

Typically the A-weighted sound pressure level of the product
is 72 dB(A). Uncertainty K = 3 dB.
The noise level when working can exceed 80 dB(A).

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-11:
Cutting board: a

h

= 19 m/s

2

, K = 6.0 m/s

2

,

Cutting wooden beam: a

h

= 20 m/s

2

, K = 3.0 m/s

2

.

The vibration emission level given in this information sheet has
been measured in accordance with a standardised test given
in EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The technical specifications of the power tool deviate from
the test criteria laid out in the standardised test given in
EN 60745.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Mounting and Operation

Starting



Before any work on the machine (e. g. maintenance,
changing the tool, etc.) as well as during its transport
and storage, lock the On/Off switch in the off position.

There is danger of injury when the On/Off switch is unin-
tentionally actuated.

Battery Charging



Do not use other battery chargers.

The supplied battery

charger is designed for the Lithium-Ion battery in your ma-
chine.



Observe the mains voltage!

The voltage of the power

supply must correspond with the data given on the name-
plate of the battery charger. Battery chargers marked with
230 V can also be operated with 220 V.

Battery Charger

Article number

EU

UK
AU

2 609 003 916
2 609 007 262
2 609 003 932
2 609 004 762

Input voltage

V

100 – 240

Charging current

mA

500

Allowable charging temperature
range

° C

0 – 45

Weight according to
EPTA-Procedure 01/2003

kg
kg
kg

0.088 (EU)
0.093 (UK)

0.085 (AU)

Protection class

 /

II

Battery

Li-Ion

Rated voltage

V=

10.8

Capacity

Ah

1.5

Charging period (battery dis-
charged)

h

3.5

Number of battery cells

3

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9

Sabre saw

Keo

Please observe the article number on the type plate of your machine.
The trade names of the individual machines may vary.

Action

Figure

Page

Delivery Scope

1

213

Battery Charging

2

213

Mounting the Hook

3

214

Checking if the Hook fits correctly

4

214

Inserting/Replacing the Saw Blade

5

215

Checking if the Blade is connected

6

215

Starting

7

215

Controlling the Stroke Rate

7

215

Working Advice

8 – 9

216 –  217

Maintenance and Cleaning

10

217

Selecting Accessories/Spare Parts

11

218
