9

10

Press the button    , and the vacuum-mop will clean all areas by first

cleaning along edges and walls and then in an S-shape pattern. Once the

cleaning is complete, the vacuum-mop will automatically return to the

charging dock to charge.

Notes:

 · Before a cleaning task, make sure the vacuum-mop is fully charged and starts from the

charging dock. Do not move the charging dock while the vacuum-mop is cleaning.

 · This cleaning diagram is for illustrative purposes only. Results may vary depending on the

actual conditions.

If the vacuum-mop starts running low on battery during a cleaning task, it will

automatically return to the charging dock to recharge, then resume cleanup

where it left off after being charged sufficiently.

Start Cleaning

How to Use

When there is a connection loss between your phone and the vacuum-

mop due to the router reconfiguration, wrong password or so:

1. Please open the cover of the vacuum-mop so that you can see the Wi-Fi

indicator.
2. Simultaneously press and hold the buttons   and

 until you hear a

voice saying "Waiting for the network configuration".

3. When the Wi-Fi indicator blinks, the Wi-Fi connection has been reset

successfully.

Area 1 cleaned

Area 4 to be cleaned

Area 2 cleaned

Area 3 cleaning

Installation

Remove Protective Coverings

Install the Side Brush

Before using the vacuum-mop, remove the protective strips from both sides.

Insert the side brush into the attachment slot on the bottom of the vacuum-

mop.

Place Charging Dock Against Wall and Charge

 ·

Place the charging dock near an electrical outlet in an area with a good

Wi-Fi signal.

 ·

Tidy up loose cord as shown in the figure to prevent the vacuum-mop

from getting tangled, which could accidentally move or unplug the

charging dock.

 ·

Place the vacuum-mop onto the charging dock. The vacuum-mop will

automatically turn on and begin charging.

 ·

After 10 minutes of the full charge of the battery, the indicator goes off.

> 0.5 m

> 0.5 m

> 1.5 m

Tidy up Any Loose Cord

Notes:

 · Fully charge the vacuum-mop before using it for the first time.

 · The vacuum-mop will remain on while connected to the charging dock.

 · When the vacuum-mop is left at the dock, it will consume a small amount of electricity to

allow the battery to maintain optimal performance in sleep mode.

Side Brush Clip

Connect with Mi Home/Xiaomi Home App

This product works with the Mi Home/Xiaomi Home

app*. Use the Mi Home/Xiaomi Home app to control

your device, and to interact with other smart home

devices.
Scan the QR code to download and install the app.

You will be directed to the connection setup page

if the app is installed already. Or search "Mi Home/

Xiaomi Home" in the app store to download and

install it.
Open Mi Home/Xiaomi Home app, tap "   " on the upper right, and then

follow prompts to add your device.

* The app is referred to as Xiaomi Home app in Europe (except for Russia).

The name of the app displayed on your device should be taken as the

default.

Notes:

 · Only 2.4 GHz Wi-Fi networks are supported.

 · The version of the app might have been updated, please follow the instructions based

on the current app version.

Reset Wi-Fi

Resume Cleanup

7714C808
