19

20

Specifications

Vacuum-Mop

Charging Dock

Name

Robotic Vacuum Cleaner

Model

STYTJ05ZHMHW

Dimensions

353 × 350 × 98.8 mm

Battery

14.4 V    /4800mAh

(

Rated Capacity

)

Charging Time

Approx. 6.5 hours

Net Weight

4.08 kg

Wireless Connectivity

Wi-Fi IEEE 802.11b/g/n 2.4 GHz

Compatible with

Android 4.4 & iOS 10.0 or above

Rated Voltage

14.4 V

Rated Power

46 W

Operation Frequency

2400–2483.5 MHz

Maximum Output Power

< 20 dBm

Model

CDZ2103

Dimensions

130 × 126 × 93 mm

Rated Input

100–240 V ~ 50/60 Hz 0.5 A

Rated Output

19.8 V   1 A

WEEE Disposal and Recycling Information

All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be mixed

with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a

designated collection point for the recycling of waste electrical and electronic equipment, appointed by the government or local authorities.

Correct disposal and recycling will help prevent potential negative consequences to the environment and human health. Please contact the

installer or local authorities for more information about the location as well as terms an conditions of such collection points.

Under normal use of condition, this equipment should be kept a

separation distance of at least 20 cm between the antenna and the body

of the user.

Issue

Possible Cause and Solution

Why doesn't the vacuum-mop carry out the

scheduled cleanup?

Check whether the battery level is sufficient. The vacuum-mop needs to have a battery level of 15%

or more to start a scheduled cleanup.

What should I do when no water or very little

water comes out when mopping the floor?

Please check whether the water compartment is filled and the mop is properly installed. Please

clean the mop on a regular basis.

What should I do when too much water comes

out of the mopping assembly?

Make sure the water tank lid is securely closed.

Why doesn't the vacuum-mop resume cleaning

after charging?

The vacuum-mop does not resume cleaning in do not disturb (DND) mode, or after manually being

returned to the dock to charge.

Why doesn't the vacuum-mop return to the

charging dock after being moved?

Moving the vacuum-mop may cause it to re-position itself or re-map its surroundings. If the vacuum-

mop is too far from the charging dock, it might not be able to automatically return on its own, in

which case you need to manually place the vacuum-mop onto the charging dock.
