Routine Maintenance

Wheel

Axle

Holder

Side Brush

Note: It is recommended to clean the side brush monthly and replace every 3 to 6 months.

1. Flip the vacuum-mop over, then gently pull out the side brush as

shown in the diagram below to clean it.
2. Reinstall the side brush.

Mop Pad

Note: The mop pad should be cleaned after each use.

1. Pull the mop pad off of the mopping module to remove it.

Omnidirectional Wheel

Note: The wheel can be cleaned with water and reinstalled after drying.

1.  Flip the vacuum-mop over and pull out the omnidirectional wheel.
2. Remove hair, dirt, and other debris from the wheel and axle.
3. Reinsert the wheel and press it firmly back into place.

Note: Filter must be fully dry before use (allow at least 24 hours).

3. Remove the filter as shown in the diagram, forcefully shake it to

remove excess water, then place it aside to dry before reinstalling it.

Cliff Sensor

Charging Contacts

Movement Sensor

Infrared Deceleration
Sensor

Vacuum-Mop Sensors

Use a soft cloth to clean all sensors in the vacuum-mop, including:
·  The four cliff sensors on the bottom.
·  The infrared deceleration sensor on the front.
·  The charging contacts on the bottom.
·  The movement sensor on the bottom.

Note: Remove the pad from the mopping module before cleaning it, and make sure dirty water

does not flow back into the water outlet to avoid clogging. Do not press too hard on the mop pad,

as this can hinder its performance. Pad should be cleaned before each use. It is recommended to

change the mop pad every 3 to 6 months.

2. Clean and dry the mop pad.
