Specifications

Model

Dimensions

Battery

Net Weight

Wireless Connectivity

Rated Voltage

Rated Power

STYTJ01ZHM

353×350×81.5 mm

14.4 V         /2400 mAh(Rated Capacity)

3.6 kg

Wi-Fi IEEE 802.11b/g/n    2.4 GHz

14.4 V

40 W

Dimensions

Rated Input

Model

Rated Output

130×126×93 mm

100-240 V ~ 50/60 Hz   0.5 A

19.8 V

  1 A

CDZ1902

Vacuum-Mop

WEEE Information

Charging Dock

Problem Type

Vacuum-mop does not perform scheduled
cleaning

Does the vacuum-mop need to be fully
charged for 16 hours the first three

times it is used?

No water comes out of the mopping
module, or only a little bit comes out

Too much water comes out of the
mopping module

Vacuum-mop doesn't resume cleaning
after charging

Does leaving the vacuum-mop on the
charging dock consume power if it's
already charged?

Vacuum-mop doesn't return to charging
dock after being moved

Solution

Vacuum-mop has low battery. Scheduled cleaning will not start unless the vacuum-mop

has at least 15% battery left.

Leaving the vacuum-mop on the charging dock after it's fully charged consumes very

little electricity and helps maintain optimal battery performance.

Lithium batteries do not suffer from memory effects, so it is not necessary to wait 16

hours after fully charging the vacuum-mop before using it.

Make sure the water tank lid is securely closed.

Make sure the vacuum-mop is not set to Do Not Disturb mode, which will prevent it

from resuming cleaning.
The vacuum-mop does not resume cleaning when it is manually recharged or placed

onto the charging dock.

Moving the vacuum-mop may cause it to re-position itself or re-map its surroundings. If

the vacuum-mop is too far from the charging dock, it might not be able to automatically

return on its own, in which case you need to manually place the vacuum-mop onto the

charging dock.

Confirm that the water tank is filled with water, and clean the mop pad if necessary.

Make sure the mop pad is installed correctly according to the user manual.

All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be

mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste

equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed by the

government or local authorities. Correct disposal and recycling will help prevent potential negative consequences to the environment

and human health. Please contact the installer or local authorities for more information about the location as well as terms and

conditions of such collection points.
