20

To remove the fold back hard floor adapter from the carpet spraying

nozzle, push the slide upwards and then press the red nozzle lock

towards the inside. Release the hard floor adapter from its hinge and

remove.
Proceed in the reverse order to fit the wipe adapter.
The microfibre pad is to be run over the strip so that the nozzle suction

channel is open or remains open.

Set the water volume control-

ler (25) to “min”. Start spraying

operation for 2–3 seconds and

moisturise microfibre pad (white).

Wetting the surface has to be

avoided because under these cir-

cumstances wetting of edge area

of parquet or floor elements is

not adequately protected against

moisture.

Window cleaning

Fit the wipe adapter to the carpet spray nozzle. To assemble see

maintenance cleaning instructions for smooth floors.
The microfibre pad for window cleaning (grey) is to be connected to

the wiper.
You can clean and dry your windows and glass surfaces at the same

time by this method.

Procedure see carpet cleaning

Upholstery cleaning

Use the upholstery spraying nozzle to clean upholstered furniture, car

seats, etc. Push this nozzle on the grip. Connect the spraying hose to

the shut-off valve.
When cleaning upholstery make sure that not too much liquid is

applied because you will have to take a longer drying time into

account depending on the floor underneath.
Flow rate control on the hand grip.

See carpet cleaning for procedure.

We recommend

THOMAS ProTex cleaning agent

 for uphols-

tery cleaning.

Cleaning and care

only service and clean the appliance when it is switched off and

the mains power plug has been disconnected from the mains power

supply.

after dry vacuuming

–   The hygiene box can, if needed, be cleaned.
  For this, take out the HEPA bag and dismantle the activated car-

bon filter.

  The inside of the hygiene box can now be cleaned with a damp

cloth. If it is very dirty, it can be cleaned in the dishwasher.

  Allow the hygiene box to completely dry before putting back the

complete filter.

  Replacement interval for the activated carbon filter: every 12

months, replace the HEPA bag if required.

after wash cleaning

   Please use a moist soft cloth to clean the appliance housing.

Do not use any aggressive cleaning detergent or solvents.

Remove fresh water tank and empty.

Empty waste water tank.

Clean anti-swash insert, waste water tank and wet filter using

clear, possibly warm water.

Check motor protection filter for contamination and clean

under flowing water and renew, if necessary.

    Keep float (13b) in the waste water tank clean and fully

functional at all times. This float interrupts the suction operation

if the waste water tank is full.

Dry up spray water in suction chamber with soft cloth.

Remove contamination on the intake connector and on the

inside of the housing cover.

The housing cover can be taken off the appliance

for easier cleaning.

To do this open the cover and swing down vertically. Press the

cover forwards until it slides out of the hinge. Afterwards swing

the cover upwards and out of the way.

Insert in the housing cover vertically and close it to fasten. The

cover automatically clicks into the hinge.

  Fill the fresh water tank with clear water to service

the pump and valves and to make the appliance

ready for operation.
Put the spraying system into operation (operate

the lever on the shut-off valve) over a wash basin,

for example.

The appliance and accessory parts are to be thoroughly dried

after being used for cleaning.

Press the shut-off valve lever to make the system completely

pressureless.

mKa microfilter

The MKA microfilter (19) is to be replaced every six months.
To do this press down the two plastic lugs on the blow-out cover and

fold it back.
Replace the MKA microfilter. Close the blow-out cover again.

 Further supplies / special accessories

An extensive range of special accessories and further supplies are

available for your THoMAS HYGIENE T2.
Get further details by returning the accompanying reply card to us or

get further information from your specialist dealer or directly from the

THoMAS Customer Service Department.

Note!

You can only assure a properly functioning appliance and efficient

cleaning by using original THoMAS accessories.

800 ml

max.

250 ml

min.
