19

Empty the waste water tank after you have used up all the

cleaning agent from the fresh water tank to prevent the

appliance being switched off automatically.

Should you not observe the above-mentioned instructions the

float will automatically switch off the appliance as soon as the

waste water tank is full. (You will clearly hear the motor be

running at a higher speed.)

Switch off appliance, disconnect the mains plug and empty the

waste water tank.

hard floor cleaning

Drop the hard floor adapter over

the carpet spraying nozzle and

lock by means of the slide.
By using this system you can clean

and dry your hard floor coverings

such as tiles, stone floors and PVC

at one and the same time.

See carpet cleaning for

procedure.

We recommend

THOMAS ProFloor cleaning agent

 for hard

floor cleaning.

Maintenance cleaning of smooth floor coverings such

as linoleum, PVC, tiles, polished stone floors and lami-

nate floors with the microfibre pad

– General instructions:

Proper care of floors is an essential component

under our terms of guarantee!

To be observed without fail are the special care

instructions of the manufacturer of the floor

coverings.

The surface protection finish can be damaged or destroyed when

cleaning and using aggressive universal cleaners.

Maintenance cleaning is to be carried out by dust suction or by wiping

over with moist cloth.

Atomised moisturisation means: The floor must be completely dry

after 3-5 minutes. This method is only to be used on laminate floors

when recommended by manufacturer.
Wash the microfibre pad before using it for the first time to remove

any possible residue given as a result of the production process.

We recommend

THOMAS ProFloor cleaning agent

for main-

tenance cleaning of smooth floor coverings such as linoleum, PVC,

tiles, polished stone floors and laminate floors.

Dismantling/assembling:

1.

2.

3.

5.

4.

6.

   We  recommend

THOMAS ProTex original cleaning

detergent

 for cleaning carpets.

See label on the cleaning agent bottle for application and

dosage.

Use hand warm water (max. 30°C).

Connect up suction hose and fit telescopic suction tube.

 Fit carpet spray nozzle, spraying hose to the suction tube with

fast coupling and move upwards and place on the shut-out

valve and lock by turning. Afterwards fasten the spray hose

by means of the two tube clips on the suction tube.

Pull out the mains power supply plug and cable from the

appliance and connect up.

Switch on the appliance and set for maximum suction power. Switch

on pump. Control lamp comes on.

Press the lever on the shut-off valve (24) until the cleaning agent

escapes. Draw the nozzle straight over the carpet and press

it down at the same time. The spraying volume can be set as

required by means of the setting wheel on the handle. Release

the valve lever to stop spraying at the end of one run or when

stopping work. When the sprayed liquid has been sucked up,

lift the nozzle and begin a new run but overlap slightly. In this

way you can clean the entire area section by section.

Should there still be traces of liquid remaining on the cleaned

areas this liquid can be sucked up without having to spray

again.

    Make sure that the mechanical suction controller (25) is

completely closed.

In the case of very stubborn dirt you can apply the cleaning

agent while moving the carpet spraying nozzle forwards. The

same treatment can also be applied by just putting the pump

into operation.

Ensure that you do not spread too much liquid over the carpeting

since this may cause waves or bumps in the carpet. However, these

will disappear again after being allowed to dry for a longer period

of time.

Absaugen und

Aufrichten

Arbeitsrichtung
Einsprühen

Sa

ug

roh

r

Dr

uc

kle

itu

ng

Lösen und Auswaschen

Suction tube

Releasing and washing out

 Spraying

Sucking up and

straightening

Pressur

e line

Working direction

Spray extraction system

•

Spray the cleaning agent deep into the carpet under pressure

•

This releases the dirt and washes out deep down into the fibres

•

Suck up the dirty water at full power and straighten up the

carpet pile again.

This should be always carried out in a single operation.

2.

1.
