42

* Depending on model

Replacement parts and accessories

Before using for the first time

Figure

Push the handle onto the flexible tube and until it
engages.

Figure

Push the crevice nozzle and upholstery nozzle back
into the accessories holder as indicated.

Setting up

Figure
a)

Push the flexible hose adapter into the air intake
opening on the vacuum cleaner lid until it engages.

b)

To remove the flexible hose, press the two lugs
together and pull the tube out.

3

2*

1*

Figure
a)

Connect the handle and the telescopic tube together.

b)

Push the handle into the telescopic tube until
it engages.
Press on the locking collar and pull out the
telescopic tube to disconnect.

Figure
a)

Connect the floor tool and the telescopic tube

together.

b)

Push the telescopic tube into the connecting piece of
the floor tool until it engages.
Press on the locking collar and pull out the
telescopic tube to disconnect.

Figure

To adjust the length of the telescopic tube, adjust
the adjusting sleeve/sliding switch in the direction of
the arrow and adjust the tube to the required length.

Figure

Holding the power cord by the plug, pull out the
required length and plug it into the mains socket.

Figure

Press the on/off button in the direction of the arrow
to switch your vacuum cleaner on/off.

Controlling the suction level

Figure
Adjust the suction by turning the on/off button in the
direction of the arrow.
The suction level can be infinitely adjusted to the level
required by turning the control knob in the direction of
the arrow.

Low power range

=>

For vacuuming delicate materials, e.g. delicate
upholstery, curtains, etc.
Medium power range

=>

For daily vacuuming of lightly soiled floors.
High power range

=>

For vacuuming durable floor coverings, hard floors
and surfaces with heavy deposits of dirt.

9

8

7

6*

5*

4*

A  Replacement filter package

 To get the most out of your appliance, we recom-
mend using PowerProtect genuine replacement
bags (BBZ41FGALL).

 Contents:

   - 4 dust bags with fasteners

   - 1 micro-hygiene filter

!

PLEASE NOTE

   We therefore recommend that you only use our origi-

nal dust bags.

 Your appliance is a highly efficient vacuum cleaner
that achieves excellent cleaning results when used
with high-quality dust bags. Only by using high-
quality dust bags (such as Bosch original dust bags)
can you ensure that your vacuum cleaner is working
at the energy efficiency class, dust pick-up rate and
dust retention capacity listed on its EU energy label.

 The use of inferior-quality dust bags (e.g. paper
bags) can have a negative effect on the ser vice life
and per formance of your appliance. Using unsuitable
or inferior-quality dust bags can also damage your
vacuum cleaner. Such damage is not covered by our
guarantee.

 You can find more information about this at

 www.bosch-home.com/dust-bag. You can order our
original vacuum cleaner bags here.

B Textile filters (permanent filters)

BBZ10TFG

Reusable bag with Velcro(R) fastener.

C Hepa filter

BBZ153HF

Additional filter for cleaner exhaust air.
Recommended for allergy sufferers. Replace once a
year.

D Micro-active carbon filter

BBZ192MAF

Combination of micro filter and active carbon filter.
Combats unpleasant odours. Replace twice a year.
Replace carbon filter frame with micro filter frame.

Please note!

It is not possible to combine a Hepa

filter and a Micro-active carbon filter.

E TURBO-UNIVERSAL

®

brush for upholstery

BBZ42TB

Hard-floor brush

BBZ123HD

For vacuuming hard floors (parquet flooring, tiles,
terracotta, etc.)
