51

* Dependent on model

Vacuuming with accessories

Figure

12*

Attach the nozzles to the suction pipe or handle as re-
quired:

a)

 Hard-floor nozzle*

  - with clip-in edge-cleaning bristles:

 of hard floor coverings (tiles, parquet, etc.)

  - without edge-cleaning bristles:

 For cleaning dir t in gaps and cracks

‡

The edge-cleaning bristles can be removed by
pushing the two catches in the direction of the ar-
rows.

b)

Crevice nozzle* for vacuuming crevices and corners,
etc.

c)

 Upholster y nozzle* for vacuuming upholstered furni-
ture, cur tains, etc.

   After each use, reinser t the combination nozzle into

the accessories holder.

d)

Furniture brush

   For cleaning window frames, cabinets, mouldings,

etc.

e)

Mattress nozzle*

  For cleaning mattresses, upholster y, etc.

Drill dust nozzle

Figure

13*

‡

 Fasten the drill dust nozzle onto the handle and po-
sition it on the wall so that the drill hole opening on
the nozzle is placed directly over where the hole is
to be drilled.

‡

 Set the appliance to the lowest power level and then
switch it on.

‡

The drill dust nozzle is held in the required position
by suction. Depending on the condition of the wall to
be drilled, you may need to adjust to a higher power
setting to ensure that the drill dust nozzle remains
in place.

   During drilling, the fine dust is automatically vacu-

umed up.

Figure

14

You can use the parking aid on the side of the appliance
if you want to stop vacuuming for a shor t time.

‡

After switching off the appliance, slide the hook on
the floor nozzle into the parking aid.

Figure

15

When vacuuming stairs, the appliance must be positi-
oned at the bottom of the stairs. If it does not reach
far enough, the appliance can also be carried using the
carr ying handle. After vacuuming

Figure

16

a)

Switch off the appliance.

‡

Unplug the mains plug.

b)

Briefly pull on the mains cable and then let go. (The
mains cable retracts automatically.)

Figure

17*

‡

Release the telescopic tube by moving the sliding
switch or adjusting sleeve in the direction of the ar-
row, and slide one tube into the other.

Figure

18

To store/transpor t the appliance, you can use the sto-
rage aid on the underside of the appliance.

a)

 Prop up the appliance on the hose or dust container
handle.

b)

 Slide the hook on the floor nozzle into the storage
aid.

‡

  In order to save space and to facilitate transpor t,
wind the suction hose around the appliance and the
telescopic tube.

c)

The appliance can also be transported using the
handle on the dust container.

Disassembly

Figure

19

‡

To remove the suction hose, press the two catches
together and pull out the hose from the appliance's
air intake opening.

Figure

20*

a)

 Telescopic tube without accessor y connection:

   To release the connection, turn the handle slightly

and pull it out of the telescopic tool.

b)

 Telescopic tube with accessor y connection:

   To release the connection, press the locking collar

on the telescopic tube and and pull out the handle.

Figure

21*

a)

 Nozzle without accessor y connection:

   To release the connection, turn the telescopic tube

slightly and pull it out of the floor nozzle.

b)

 Nozzle with accessor y connection:

   To release the connection, press the locking collar

and pull the telescopic tube out of the floor nozzle.

Cleaning and maintenance

Emptying the dust container

Figure

22

In order to achieve the best possible vacuuming results,
the dust container should be emptied after ever y use
or, at the latest, when dust in the dust container has
reached the marking at any point.
The display lights up red (Smar tSensor Control) if the
dust container has to be emptied.

Figure

24

!

 Caution

   The dust container can only be removed when the

appliance is in a horizontal position. Therefore,
place the appliance on the floor to unlock the re-
lease button.

Figure

23

a)

 Hold the dust container at the handle and press on
the release button to remove it from the appliance.

b)

 Release the lid from the dust container by pulling on
the tab, and open the dust container.

c)

Remove the lid from the dust container and empty
the dust container.

d)

 Check the fluff filter and rinse it under running wa-
ter, if necessar y. Allow to dr y before putting it back
in the dust container. Close and lock the lid.
