* Dependent on model

Spare parts and optional accessories

A  BBZ123HD hard-floor nozzle

For vacuuming smooth floors
(parquet, tiles, terracotta, etc.)

B  BBZ124HD hard-floor nozzle

Includes two rotating brush rollers

For caring for expensive hard floors
and for the improved collection of
coarse dir t.

Before using the appliance for the first

time

Figure

1*

‡

 Push the handle onto the suction hose and lock it in
place.

Starting the appliance

Figure

2

‡

 Push the suction-hose adapter into the air intake
opening on the appliance and lock it in place. You
will hear an audible 'click'.

Figure

3*

a)

 Telescopic tube without accessor y connection:

  Push the handle into the telescopic tube.

b)

 Telescopic tube with accessor y connection:

   Push the handle into the telescopic tube until it

locks into place.

Figure

4*

a)

 Nozzle without accessor y connection:

   Push the telescopic tube into the connecting piece

of the floor nozzle.

b)

 Nozzle with accessor y connection:

   Push the telescopic tube into the connecting piece

of the floor nozzle until it locks in place.

Figure

5*

‡

 Unlock the telescopic tube by moving the sliding
switch or adjusting sleeve in the direction of the ar-
row, and adjust it to the desired length. The slide
resistance  on  carpet  is  at  its  lowest  when  the  tele-
scopic tube has been fully extended.

Figure

6*

‡

 Attach the accessories holder to the multi-purpose
nozzle and clip it onto the suction pipe/telescopic
tube.

Figure

7

‡

Holding the mains cable by the plug, pull it out to
the required length and plug the plug into the mains
socket.

Figure

8

‡

To switch the vacuum cleaner on or off, press the
ON/OFF button.

Controlling the suction level

Figure

9

 Controlling the suction power

Turn the rotar y control to infinitely adjust the suction
level to the level required.
min -

For vacuuming cur tains and delicate textiles

 -   For vacuuming upholstered furniture and

cushions

 -   For vacuuming delicate rugs und for daily vacu-

uming of lightly soiled floors

 -   For vacuuming durable floor coverings

max -

For vacuuming hard floors and heavily soiled
rugs and carpets

Figure

10*

Telescopic tube with sliding switch and au-

xiliary air control

The suction power can also be adjusted by turning the
auxiliar y air control switch in the direction of the arrow.

„

Auxiliary air control switch open

=> suction power reduced

„

Auxiliary air control switch closed

=> maximum suction power

Vacuum-cleaning

!

 Caution

   Floor nozzles are subject to a cer tain amount of

wear, depending on the type of hard floors you have
(e.g. rough, rustic tiles). You should therefore check
the underside of the floor nozzle at regular inter vals.
Worn undersides of floor nozzles may have sharp
edges that can damage delicate hard floors, such as
parquet or linoleum. The manufacturer does not ac-
cept any responsibility for damage caused by worn
floor nozzles.

Figure

11

Set the switchable floor nozzle as follows:

„

 Rugs and carpets =>

„

 Hard floors/parquet =>

If you are vacuuming up relatively large par ticles, make
sure that you vacuum them up successively and careful-
ly to ensure that the floor nozzle's air intake duct does
not become blocked.
If necessar y, you should lift up the nozzle in order to
better vacuum up the dir t par ticles.
