Installation

91

EN

Carefully screw the hose connector

3

 to the

appliance’s gas connector

1

 (½” thread

ISO 228-1), placing the seal

2

 between

them. The hose connector

4

 can also be

screwed to the hose connector

3

,

depending on the diameter of the gas hose
used. After having tightened the hose
connector(s), push the gas hose

6

 onto the

hose connector and secure it with the
clamp

5

 that is compliant with the standard

in force.

Connection with a steel hose

Make the connection to the gas mains
using a continuous wall steel hose whose
specifications comply with the applicable
standard.
Carefully screw the connector

3

 to the gas

connector

1

 of the appliance, placing the

seal

2

 between them.

Connection with a steel hose with
bayonet fitting

Carry out the connection to the gas mains
using a steel hose with bayonet fitting
compliant with B.S. 669. Apply insulating
material to the thread of the gas hose
connector

4

 and then tighten the adapter

3

.

Screw the assembly to the movable
connector

1

of the appliance, placing the

supplied seal

2

 between them.

Connection using a rubber hose
complying with current standards is
only permitted if the hose can be
inspected along its entire length.

The inside diameter of the hose
must be 8 mm for LPG and 13 mm
for Natural gas and Town gas.
