GB
- 23 -
Danger!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be
found in the enclosed booklet.
Danger!
Read all safety regulations and instructions.
Any errors made in following the safety regula-
tions and instructions may result in an electric
shock,
fi
re and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
Special information about the laser
Caution: Laser radiation
Do not look into the beam
Laser class 2
VORSICHT ! - LASERSTRAHLUNG !
Nicht in den Strahl blicken!
Laserspezifikation
Laser Klasse 2;
Ǹ
: 650 nm; P
0
Ɠ̞ʸÃ
Ä·¹¾ʽʷʿʹʼƖʸ
•
Never look directly into the laser path.
•
Never direct the laser beam at reflecting sur-
faces or persons or animals. Even a low out-
put laser beam can inflict injury on the eye.
•
Caution: It is vital to follow the work proce-
dures described in these instructions. Using
the equipment in any other way may result in
hazardous exposure to laser radiation.
•
Never open the laser module.
•
It is prohibited to carry out any modifications
to the laser to increase its power.
•
The manufacturer cannot accept any liability
for damage due to non-observance of the
safety information.
2. Layout and items supplied
2.1 Layout (Fig. 1-3/7/8/20)
1. Handle
2. On/O
ff
switch
3. Release
button
4. Machine
head
5. Saw shaft lock
6. Adjustable blade guard
7. Saw
blade
8. Clamping
device
9. Removable stop rail, left
10. Adjustable workpiece support
11. Removable stop rail, right
12. Table insert
13. Adjustable foot
14. Locking screw
15. Pointer (saw table)
16. Scale (saw table)
17. Turntable
18. Fixed saw table
19. Scale (saw head)
20. Pointer (saw head)
21. Locking grip
22. Sawdust bag
23. Drag guide
24. Locking screw for drag guide
25. Fastening bolt
26. Locking screw for clamping device
27. Knurled screw for cutting depth limiter
28. Stop for cutting depth limiter
29. LED lamp
30. Laser
31. Flange bolt
32. Outer
fl
ange
33. Button
34. Transport handle
35. On/O
ff
switch for LED lamp
36. On/O
ff
switch for laser
37. Adjustment screw (45° left setting)
38. Adjustment screw (45° right setting)
39. Adjustment screw (0° setting)
40. Fixed workpiece stop
41. Folding longitudinal stop
42. Button
43. Locking screw for stop rail
44. Holder for clamping device (horizontal)
Anl_TE_SM_2131_Dual_SPK7.indb 23
Anl_TE_SM_2131_Dual_SPK7.indb 23
13.05.14 16:04
13.05.14 16:04
