ENGLISH

WARNING:

BE SURE TO TIGHTEN THE HEX

BOLT CLOCKWISE SECURELY. Also be careful

not to tighten the bolt forcibly. Slipping your hand

from the hex wrench can cause a personal injury.

WARNING:

Make sure that the protrusion "a"

on the inner flange that is positioned outside fits

into the saw blade hole "a" perfectly.

 Mounting the

blade on the wrong side can result in the dangerous

vibration.

For tool with the inner flange for a

15.88 mm hole-diameter saw blade

(country specific)

Mount the inner flange with its recessed side facing

outward onto the mounting shaft and then place circu-

lar saw blade (with the ring attached if needed), outer

flange and hex bolt.

For tool without the ring

►

Fig.24:

1.

 Mounting shaft

2.

 Inner flange

3.

 Circular

saw blade

4.

 Outer flange

5.

 Hex bolt

For tool with the ring

►

Fig.25:

1.

 Mounting shaft

2.

 Inner flange

3.

 Circular

saw blade

4.

 Outer flange

5.

 Hex bolt

6.

 Ring

WARNING:

BE SURE TO TIGHTEN THE HEX

BOLT CLOCKWISE SECURELY. Also be careful

not to tighten the bolt forcibly. Slipping your hand

from the hex wrench can cause a personal injury.

WARNING:

If the ring is needed to mount the

blade onto the spindle, always be sure that the

correct ring for the blade's arbor hole you intend

to use is installed between the inner and the outer

flanges.

 Use of the incorrect arbor hole ring may

result in the improper mounting of the blade causing

blade movement and severe vibration resulting in

possible loss of control during operation and in seri-

ous personal injury.

Blade guard cleaning

When changing the circular saw blade, make sure to

also clean the upper and lower blade guards of accu-

mulated sawdust as discussed in the Maintenance

section. Such efforts do not replace the need to check

lower guard operation before each use.

Connecting a vacuum cleaner

Optional accessory

When you wish to perform clean cutting operation,

connect a Makita vacuum cleaner to your tool. Connect

a hose of the vacuum cleaner to the dust nozzle using

the front cuff 24.

►

Fig.26:

1.

 Hose of the vacuum cleaner

2.

 Front cuff

24

3.

 Dust nozzle

Adjusting angle of dust nozzle

The angle of the dust nozzle can be adjusted by rotating

the dust nozzle.

When operating the tool without connecting a vacuum

cleaner, bring the dust nozzle downward to prevent the

operator from being exposed to sawdust.

When operating the tool with connecting a vacuum cleaner,

bring the dust nozzle upward to keep the hose of the vacuum

cleaner from getting caught in the workpiece or the guide rail.

►

Fig.27:

1.

 Dust nozzle

OPERATION

This tool is intended to cut wood products. With appro-

priate Makita genuine circular saw blades, following

materials can also be sawed:
•

Aluminum products

•

Mineral contained plastic

Refer to our website or contact your local Makita dealer

for the correct circular saw blades to be used for the

material to be cut.
Do not use the tool without the sub base unless when

using the guide rail.

CAUTION:

When cutting plastic materials,

avoid melting it by overheating of the blade tip.

Checking blade guard function

Set the bevel angle to 0°, and then retract the lower

guard manually to the end and release it. The lower

guard is properly functioning if;
—  it is retracted above the base without any hin

-

drance and;

—  it automatically returns and contacts with the

stopper.

►

Fig.28:

1.

 Upper guard

2.

 Lower guard

3.

 Base

4.

 Stopper

5.

 Open

6.

 Close

If the lower guard is not functioning properly, check if

saw dust is accumulated inside of the upper and lower

guards. If the lower guard is not functioning properly

even after removing dust, have your tool serviced at a

Makita service center.

Cutting operation

CAUTION:

Wear dust mask when performing

cutting operation.

CAUTION:

Be sure to move the tool forward

in a straight line gently.

 Forcing or twisting the tool

will result in overheating the motor and dangerous

kickback, possibly causing severe injury.

NOTE:

 When the battery cartridge temperature is

low, the tool may not work to its full capacity. At this

time, for example, use the tool for a light-duty cut for

a while until the battery cartridge warms up as high

as room temperature. Then, the tool can work to its

full capacity.

►

Fig.29
