22 ENGLISH

MAINTENANCE

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed before

attempting to perform inspection or maintenance.

CAUTION:

Clean out the upper and lower guards

to ensure there is no accumulated sawdust which may

impede the operation of the lower guarding system.

 A

dirty guarding system may limit the proper operation which

could result in serious personal injury. The most effective

way to accomplish this cleaning is with compressed air.

If

the dust is being blown out of the guards, be sure the

proper eye and breathing protection is used.

CAUTION:

After each use, wipe off the saw

dust on the tool.

 Fine saw dust may come inside the

tool and cause malfunction or a fire.

NOTICE:

Never use gasoline, benzine, thinner,

alcohol or the like. Discoloration, deformation or

cracks may result.

To maintain product SAFETY and RELIABILITY,

repairs, any other maintenance or adjustment should

be performed by Makita Authorized or Factory Service

Centers, always using Makita replacement parts.

Adjusting 0°-cut or 45°-cut accuracy

This adjustment has been made at the factory. But if it is

off, you can adjust it as the following procedure.

1.

Loosen the clamping screws on the front and rear

of the tool so that the bevel angle can be changed. Set

the stopper to 0° - 45° bevel angle position if you are

going to adjust 45°-cut accuracy.

►

Fig.47:

1.

 Stopper

2.

Make the base perpendicular or 45° to the circular

saw blade using a triangular rule by turning the adjust

-

ing screw with a hex wrench. You can also use a square

rule to adjust 0° angle.

►

Fig.48:

1.

 Triangular rule

►

Fig.49:

1.

 Adjusting screw for 0° angle

2.

 Adjusting

screw for 45° angle

3.

Tighten the clamping screws and then make a test

cut to check if desired angle is obtained.

Adjusting the parallelism

CAUTION:

Keep the parallelism accurate.

Otherwise the circular saw blade may bite into the guide

rail and the damaged guide rail may cause an injury.

This adjustment has been made at the factory. But if it is

off, you can adjust it as the following procedure.

1.

Set the tool to the maximum cutting depth.

2.

Make sure all levers and screws are tightened.

3.

  Loosen the screws shown in the figure.

4.

  While opening the lower guard, move the rear of

the base so that the distance A and B becomes equal.

►

Fig.50:

1.

 Screw

2.

 Base

5.

Tighten the screws and make a test cut to check

the parallelism.

OPTIONAL

ACCESSORIES

CAUTION:

These accessories or attachments

are recommended for use with your Makita tool

specified in this manual.

 The use of any other

accessories or attachments might present a risk of

injury to persons. Only use accessory or attachment

for its stated purpose.

If you need any assistance for more details regard

-

ing these accessories, ask your local Makita Service

Center.
•

Circular saw blade

•

Rip fence (Guide rule)

• Hook
•

Guide rail

•

Bevel guide

• Clamp
• Sheet
•

Rubber sheet

•

Position sheet

•

Dust nozzle

•

Hex wrench

•

Wireless unit (for DHS783)

•

Makita genuine battery and charger

NOTE:

 Some items in the list may be included in the

tool package as standard accessories. They may

differ from country to country.
