14 ENGLISH

Using dust cup set

Optional accessory

Fit the dust cup set against the ceiling when operating

the tool.

►

Fig.35

NOTICE:

Do not use the dust cup set when drill-

ing in metal or similar. It may damage the dust

cup set due to the heat produced by small metal

dust or similar.

NOTICE:

Do not install or remove the dust cup

set with the drill bit installed in the tool. It may

damage the dust cup set and cause dust leak.

MAINTENANCE

CAUTION:

Always be sure that the tool is

switched off and unplugged before attempting to

perform inspection or maintenance.

NOTICE:

Never use gasoline, benzine, thinner,

alcohol or the like. Discoloration, deformation or

cracks may result.

To maintain product SAFETY and RELIABILITY,

repairs, any other maintenance or adjustment should

be performed by Makita Authorized or Factory Service

Centers, always using Makita replacement parts.

Replacing filter of dust case

1.

Remove the dust case while pressing down the

lever of the dust case.

►

Fig.36:

1.

 Lever

2.

  Insert the flat-blade screwdriver into the slots of

the filter cover to remove the filter case and filter.

►

Fig.37:

1.

 Flat-blade screwdriver

2.

 Filter case

3.

  Remove the filter from the filter case.

►

Fig.38:

1.

 Filter

2.

 Filter case

4.

  Attach a new filter to the filter case, and then

attach them to the dust case aligning the protrusion on

the filter case with the groove on the dust case.

►

Fig.39:

1.

 Protrusion

2.

 Groove

5.

Close the cover of the dust case, and then attach

it to the tool.

Replacing sealing cap

If the sealing cap is worn out, the performance of the

dust collection decreases. Replace it if it's worn out.

Remove the sealing cap, and then attach a new one

with its protrusion facing upward.

►

Fig.40:

1.

 Protrusion

2.

 Sealing cap

OPTIONAL

ACCESSORIES

CAUTION:

These accessories or attachments

are recommended for use with your Makita tool

specified in this manual.

 The use of any other

accessories or attachments might present a risk of

injury to persons. Only use accessory or attachment

for its stated purpose.

If you need any assistance for more details regard-

ing these accessories, ask your local Makita Service

Center.
•

Carbide-tipped drill bits (SDS-Plus carbide-tipped

bits)

•

Core bit

•

Bull point

•

Diamond core bit

•

Cold chisel

•

Scaling chisel

•

Grooving chisel

•

Chuck adapter

•

Keyless drill chuck

•

Bit grease

•

Depth gauge

•

Blow-out bulb

•

Dust cup

•

Dust cup set

•

Safety goggles

•

Plastic carrying case

NOTE:

 Some items in the list may be included in the

tool package as standard accessories. They may

differ from country to country.
