11 ENGLISH

Rotation only

For drilling in wood, metal or plastic materials, rotate
the action mode changing knob to the   symbol. Use a

twist drill bit or wood drill bit.

►

Fig.8:

1.

 Rotation only

Hammering only

For chipping, scaling or demolition operations, rotate
the action mode changing knob to the    symbol. Use a

bull point, cold chisel, scaling chisel, etc.

►

Fig.9:

1.

 Hammering only

Adjusting the nozzle position

Push in the guide while pressing the guide adjustment

button, and then release the button at the desired

position.

►

Fig.10:

1.

 Guide

2.

 Guide adjustment button

NOTE:

 Before adjusting the nozzle position, release

the nozzle forward completely by pressing the guide

adjustment button.

Adjusting the drilling depth

Slide the depth adjustment button to the desired posi

-

tion while pressing it. The distance (A) is the drilling

depth.

►

Fig.11:

1.

 Depth adjustment button

Torque limiter

NOTICE:

As soon as the torque limiter actuates,

switch off the tool immediately.

 This will help pre-

vent premature wear of the tool.

NOTICE:

Drill bits such as hole saw, which tend

to pinch or catch easily in the hole, are not appro-

priate for this tool.

 This is because they will cause

the torque limiter to actuate too frequently.

The torque limiter will actuate when a certain torque

level is reached. The motor will disengage from the

output shaft. When this happens, the drill bit will stop

turning.

Hook

CAUTION:

Never hook the tool at high loca-

tion or on potentially unstable surface.

For HR2663

►

Fig.12:

1.

 Hook

The hook is convenient for temporarily hanging the tool.

To use the hook, simply lift up hook until it snaps into

the open position. When not in use, always lower hook

until it snaps into the closed position.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and unplugged before carrying out

any work on the tool.

Side grip (auxiliary handle)

CAUTION:

Always use the side grip to ensure

safe operation.

CAUTION:

After installing or adjusting the

side grip, make sure that the side grip is firmly

secured.

Install the side grip so that the grooves on the grip fit in

the protrusions on the tool barrel. Turn the grip clock-

wise to secure it. The grip can be fixed at desired angle.

►

Fig.13:

1.

 Side grip

Grease

Coat the shank end of the drill bit beforehand with a

small amount of grease (about 0.5 - 1 g).

This chuck lubrication assures smooth action and lon-

ger service life.

Installing or removing drill bit

Clean the shank end of the drill bit and apply grease

before installing the drill bit.

►

Fig.14:

1.

 Shank end

2.

 Grease

Insert the drill bit into the tool. Turn the drill bit and push

it in until it engages.

After installing the drill bit, always make sure that the

drill bit is securely held in place by trying to pull it out.

►

Fig.15:

1.

 Drill bit

To remove the drill bit, pull the chuck cover down all the

way and pull the drill bit out.

►

Fig.16:

1.

 Drill bit

2.

 Chuck cover

Chisel angle (when chipping,

scaling or demolishing)

The chisel can be secured at the desired angle. To change

the chisel angle, rotate the action mode changing knob to

the O symbol. Turn the chisel to the desired angle.

►

Fig.17:

1.

 Action mode changing knob

Rotate the action mode changing knob to the   sym-

bol. Then make sure that the chisel is securely held in

place by turning it slightly.

Depth gauge

The depth gauge is convenient for drilling holes of uniform

depth. Loosen the side grip and insert the depth gauge

into the hole on the side grip. Adjust the depth gauge to the

desired depth and tighten the side grip firmly.

►

Fig.18:

1.

 Hole

2.

 Depth gauge

NOTE:

 Make sure that the depth gauge does not

touch the main body of the tool when attaching it.
