14

 | English

1 609 92A 3SE | (24.4.17)

Bosch Power Tools



Always wait until the machine has come to a complete

stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.



Products sold in GB only

: Your product is fitted with a

BS 1363/A approved electric plug with internal fuse
(ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should
be cut off and an appropriate plug fitted in its place by an
authorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.

Product Description and

Specifications

Read all safety warnings and all instruc-

tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for hammer drilling in concrete,
brick and stone, as well as for light chiselling work. It is also
suitable for drilling without impact in wood, metal, ceramic
and plastic. Machines with electronic control and right/left ro-
tation are also suitable for screwdriving.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Quick change keyless chuck  (GBH 240 F)

2

SDS-plus quick change chuck  (GBH 240, GBH 240 F)

3

SDS-plus tool holder

4

Dust protection cap

5

Locking sleeve

6

Lock ring for rapid-change chuck  (GBH 240 F)

7

Rotational direction switch

8

Lock-on button for On/Off switch

9

On/Off switch

10

Release button for mode selector switch

11

Mode selector switch

12

Button for depth stop adjustment

13

Depth stop

14

Auxiliary handle (insulated gripping surface)

15

Handle (insulated gripping surface)

16

Securing screw for key type drill chuck *

17

Key type drill chuck *

18

SDS-plus adapter shank for drill chuck *

19

Drill chuck mounting  (GBH 240 F)

20

Front sleeve of the quick change keyless chuck
(GBH 240 F)

21

Retaining ring of the quick change keyless chuck
(GBH 240 F)

22

Extraction sleeve of the dust extraction attachment *

23

Clamping screw for the dust extraction attachment *

24

Depth stop of the dust extraction attachment *

25

Telescopic pipe of the dust extraction attachment *

26

Wing bolt of the dust extraction attachment *

27

Guide pipe of the dust extraction attachment *

28

Universal bit holder with SDS-plus shank *

* Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Technical Data

Rotary Hammer

GBH 240

GBH 240 F

Article number

3 611 B72 1..

3 611 B73 0..

Speed control





Stop rotation





Right/left rotation





Quick change chuck

–



Rated power input

W

790

790

Impact rate

min

-1

0 – 4200

0 – 4200

Impact energy per stroke according to
EPTA-Procedure 05/2009

J

2.7

2.7

Rated speed

min

-1

0 – 930

0 – 930

Tool holder

SDS-plus

SDS-plus

Spindle collar diameter

mm

48.5

48.5

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
