Thermozone AD 200 W

  25

GB

KRT1900, Capillary tube thermostat

1-stage thermostat with a change-over con-

tact for heat regulation or fan operation.

Protection class: IP55

T10, electronic thermostat

Internal setting for a temperature range

5–30°C.

Protection class: IP30

CB30N, Control panel (3-step)

Wall mounted manual three step regulation of the fan

speed.

Controls a maximum of 6 units (max. current 10A).

Protection class: IP44

RTI2, electronic 2-step thermostat

RTI2 with adjustable temperature difference

between the steps (1– 10°C) and internal

setting for a temperature range 5–35°C.

Protection class: IP44

Accessories

ADEA, air curtain regulator

ADEA is an advanced and user friendly regulator for air

curtains. ADEA is ready to run directly after installation

on account of the pre-programmed parameters. An out-

door sensor, room sensor and door contact govern the

regulator, which adapts the heat and fan speed. In its

basic design the fan speed is controlled in 3 steps, but

can, via a 0-10V signal, govern an external controller

(ADSR54 or frequency inverter) to provide fully variable

control. A control board needs to be added,

ADEAEB

(IP55) for external mounting. One ADEA is needed for

each opening, but it may control several air curtains.

Protection class: IP30

MDC, magnetic door contact with time delay

Starts the air curtain or increases from low to high speed

when the door is opened. When the door is closed,

the fan continue running the preset time (2s –10 min).

Prevents the fan from starting/stopping continuously and

is especially suitable for doors that are frequently ope-

ned. Three alternating volt-free contacts 10A, 230V~.

Protection class: IP44
