The unit will display the current Room

temperature.

4.   And then by pressing the “ ” (1) button, the

unit will blow the cold air.

5.   Upon pressing the “+” button, start set

the suitable temperature (the highest

temperature you can set until to 35°C), when

the setted temperature is higher then room

temperature, the unit will start one heat

setting, and at this time one of the “ ” will

light up. If continue pressing “+” the setted

temperature will be even higher. The unit will

start totally 2 heat settings.At this time the 2

“ ” will light up.

6.  You can also press button “ ” (2) one or two

times to get heat directly. One time pressing

is in low heat setting, and two time pressing

is in high heat setting. When pressing this

button for third time, it will come back with

only cool air blowing mode.

7.   By pressing “ ” (3), you can set the timer

from 0-8 hours.

8.  By  pressing “ ” (4), you can make the heater

with or without oscillation.

9.  When you want to turn off the heater, you

can  press “ ” (1), this time the symbol “fan

blade” will shining, and at the meaning time,

all the heating will turn off and only fan

blowing, after blowing 30s, the heater will

cut off only showing the room temperature.

OSCILLATION BUTTON

This appliance also have an oscillation function.

To switch the function on, press the “ ” (4)

switch. To stop it, press the swing switch again.

TIMER FUNCTION

This function will work in any mode.The timer

function allows you to set the length of opera-

tion from 1 hour to 8 hours.Pressing the Timer

button increase the length of operation by 1

hour each times the button is pressed.Once the

timer has been set the timer will count down

the hours in 1hour by 1 hour ,showing on the

display the remaining operating time until the

heater will turn itself off.Pressing the timer but-

ton once more after the display reflects 8 hours

will reset the heater to continuously running.

THERMOSTAT INSTRUCTIONS

1.   To adjust temperature, press the “+” to

increase the desired temperature and “ – “ to

decrease the desired temperature

2.   When the air temperature reaches 3 degrees

above the set temperature, the heater will

cut off

3.   When the air temperature drops 1 degree

below the set temperature, the unit will

come back on.

4.   Temperature can setting from 15 degree to

35 degree

Remote control

1.   Remote control, please use Lithium battery

CR2025  3 V.

2.   The remote control power button is labeled

as  such “ ”

3.   All the functions perfomed with the remote

control work identically to the manual

controls.

SECURITY SYSTEM:

•   The fan heater is equipped with overheating

shut-off which switchs, if the temperature

inside the appliance exceeds the normal

running temperature heating element

product will automatically stop working, the

motor will continue to operate, the internal

heat shed. This protective device applies only

to the appliance itself and has no influence

on room temperature regulation.

•   If overheating occurs, remove the plug

from socket, push buttons to switch the

convector off and let it cool down for at least

10 minutes. Put the plug in the socket and

switch the heater on.

•   If you still notice the same defect above

mentioned remove the plug from socket and

have the convector serviced by authorized

service personal only.

MAINTENANCE:

•   The fan heater only needs regular cleaning

on the outside.

•   Before you clean the unit, turn the switch to

OFF. Remove the plug from socket and wait

until the fan heater cool down.

•   Use a damp cloth to wipe the heater housing.

•   Do not use water, detergents, abrasive

cleaning liquids or chemical agents (alcohol,

gasoline etc.) to clean the unit.

TECHNICAL CHARACTERISTICS

220-240 V • 50 Hz • 2000 W

This marking indicates that this product

should not be disposed with other

household wastes throughout the EU. To

prevent possible harm to the environment or

human health from uncontrolled waste disposal,

recycle it responsibly to promote the sustainable

reuse of material resources. To return your used

device, please use the return and collection

3

ENGLISH

2

ENGLISH

INSTRUCTION MANUAL

This product is only suitable for well

insulated spaces or occasional use.

•   Thank you very much for your purchase of

our Fan heater.

•   Please read the instruction manual carefully

and keep it for future use.

IMPORTANT INSTRUCTIONS

When using electrical appliances, basic

precautions should always be followed to

reduce the risk of fire, electrical shock, burns

and other injury, including the following:

1.   Study this instruction manual carefully

before using the product.

2.   The device is only intended for private and

not for any commercial use.

3.   Remove the unit from its packaging and

check to make sure it is in good condition

before using.

4.   Do not let children play with parts of the

packing (such as plastic bags).

5.   Check the household voltage to ensure it

matches the fan’s rated specification.

6.   Check the power cord and plug carefully

before use to make sure that they are not

damaged.

7.   Before unplugging the power cord, be sure

to turn off the power. When touching the

unit, be sure your hands are dry to prevent

from electric shock.

8.   Do not use near or point the heater to

furniture, curtains or other inflammable

objects. Keep back of fan heater min. 15 cm

away from walls or objects to allow free

airflow.

9.   Do not block air intakes or exhaust in any

manner to prevent a possible fire.

10.  Do not use or leave the fan heater

unattended when children, old or disabled

people are present.

11. Always unplug heater when not in use.

12.  Prevent water from getting into the housing

of the heater during operation or in storage.

Hazard of electric shock. Always store in dry

area with no moisture.

13.  Do not use in places where there are gas,

paint or other inflammable goods and

objects

14.  This heater is not intended for use in

bathrooms, laundry areas and similar indoor

locations. Never locate the heater where it

may fall into a bath tub or other bodies of

water.

15.  Do not run the cord under carpeting. Do not

cover cord with throw rugs, runners or the

like. Arrange cord away from traffic area and

where it will not be tripped over.

16.  Do not use a soft surface, like a bed, where

openings may become blocked.

17.  Use this heater only as described in this

manual. Any other uses not recommended

by the manufacturer may cause fire, electric

shock, or injury to persons and may void

warranty.

18.  Avoid the use of an extension cord because

the extension cord may overheat and cause a

risk of fire.

19. Do not use outdoors.

20.  This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities,

or lack of experience and knowledge,

unless they have been given supervision or

instruction concerning use of the appliance

by a person responsible for their safety.

21.  Children should be supervised to ensure that

they do not play with the appliance.

22. This appliance heats up when in use. To

avoid burns, do not let bare skin touch hot

surfaces. Switch off and use handles where

provided when moving.

CAUTIONS

•  This appliance is not a toy.

•  This appliance is for household use only.

•  Do not immerse the unit in the water.

•   To avoid the risk of fire or electric shock do

not remove the housing by yourself.

•   Any servicing other than cleaning and user

maintenance should be performed by an

authorized service representative.

•   If the supply cord is damaged, it must be

replaced by a special cord or assembly

available from the manufacturer or its service

agent.

•   Repair should be done by an authorized

service personal only.

Warning: In order to avoid overheating,

DO NOT COVER the heater
Do not use this heater in the immediate

surroundings of a bath, a shower or a

Swimming pool.

OPERATION

(see picture A)

1.   Place the heater on a firm level surface

2.   Setting the master button to “off ”.plug the

cord set into a 220-240 V~AC electrical outlet.

Turnning the master button “on” position.

3.   Turn the heater ON by pressing the ON/OFF

main button at the back side of the heater.
