34

11. Using optional accessories

3)

Attach the optional battery to the

charger.

Align the connectors on the battery and
charger, and press the battery until it
clicks into place. Charging starts and the
green charging indicator blinks.

2.

After the battery is fully charged, remove the battery from the charger.

The green charging indicator changes from blinking to remaining
continuously lit when the battery is fully charged.

1)

Unplug the AC adapter from the

power outlet, then disconnect the

charger.

2)

While pressing the button on the side

of the battery, lift the battery off the

charger.

3.

Mount the compressor on the battery.

Align the connector on the bottom of the compressor with that on the
battery and mount the compressor on the battery. Push the compressor
down until it clicks into place.

Note:

To separate the compressor and battery,
press the push button on the side of the
battery and lift the compressor off the battery.

3

Charging Indicator blinks

Charging Indicator
remains lit

Push Button

Push Button
