8.5  Continuity Testing with Buzzer

-   Turn the rotary switch



 of the  BENNING MM 3 to select the appropriate

range identified by a buzzer and diode symbol (

,  ).

-   Connect the black safety test lead to the COM-terminal



 of the

 BENNING MM 3.

-   Connect the red safety test lead to the input terminal for V, Ω, and Hz



 of

the  BENNING MM 3.

-   Connect the safety test leads to the circuit to be measured. If the circuit

resistance between the COM-terminal



 and the input terminal for V,

Ω and

Hz



 falls below 50 Ω, then the built-in buzzer in the  BENNING MM 3 emits

a continuous tone.

see Figure 8:

Continuity Testing with buzzer

8.6  Capacitance Measurement



CAUTION! Capacitors must be completely discharged before

attempting capacitance measurement! Never apply voltage

to the input terminals for a capacitance measurement as this

could destroy or damage the tester! A damaged tester may

present an electrical shock hazard to the user!

-

Use the rotary switch



 to select the appropriate range on the

BENNING MM 3.

-    Establish the polarity of the capacitor and discharge the capacitor completely.

-   Connect the fully discharged capacitor according to its polarity to the input

terminals for capacitance measurement



 of the  BENNING MM 3 and read

the measurement value on the digital display



 of the  BENNING MM 3.

see Figure 9:

Capacity Testing

8.7  Frequency measurement

-

Use the rotary switch



 to select the appropriate range on the

BENNING MM 3.

-   Connect the black safety test lead to the COM-terminal



 of the

 BENNING MM 3.

-   Connect the red safety test lead to the input terminal for V, Ω, and Hz



 of

the  BENNING MM 3. Observe the voltage range of the  BENNING MM 3 for

frequency measurements!

-   Connect the safety test leads to the circuit measurement points and read

the measured value on the digital display



 of the  BENNING MM 3.

see Figure 10:

Frequency measurement

9.   Maintenance



Remove test leads and turn the power off before opening the

 BENNING MM 3! Dangerous voltage!

Any work to be carried out on an opened  BENNING MM 3 under voltage

is

strictly reserved for qualified electrotechnical personnel who must take

special precautionary measures to avoid accidents.

This is how to ensure that the  BENNING MM 3 is free from any  voltage before

the instrument is opened:

-  first remove the safety test leads from measured object.

-  then remove both safety test leads from the  BENNING MM 3.

-  turn the rotary switch



 to the "OFF" position.

9.1  Instrument safe-guarding

In certain circumstances, safety during the use of the  BENNING MM 3 can no

longer be guaranteed; when for instance:

-  there is visible damage to the housing

-  measurement errors occur

-   the instrument has been subjected to prolonged storage under unfavorable

conditions and

-   the instrument has been subjected to severe transport stresses.

In such cases the  BENNING MM 3 must be immediately switched off, removed

from the measurement points and secured against any future unintentional

operation.

9.2 Cleaning

Wipe the case of the  BENNING MM 3 with a clean dry cloth (exception: spe-

cial cleaning cloths). Do not use any solvents and/or abrasives to clean the

 BENNING MM 3.
