7 - HOW TO USE CHEMICAL PRODUCTS

The models T and TX can suck detergents and other liquid additives from the built-in tank or
from a separate tank.

In the event of direct contact with detergent additives, follow instructions provided by the man-
ufacturer and/or product retailer and  rinse the affected body part with clean water.

7.1 - SUCTION FROM INTERNAL TANK

Fill the tank, as shown in Fig. 1. Select the low pressure by operating the Rototek or
Multireg 99 (Fig. 2).
Make sure that the outer chemical ports is plugged (Fig. 3).
Adjust the chemical quantity by using the suitable cursor +/- (Fig. 3).
In order to empty the tank, open the plug located at the bottom of the machine (Fig. 4).
Capacity of the built-in tank: 7,5 litres.

7.2 - SUCTION FROM EXTERNAL TANK

Remove the plug from the chemical port (Fig. 1).  Fit che connector of kit “A” into the chemi-
cal port (CHEM) and plunge the filter into the separate tank “B” (Fig. 2).
Select the low pressure by operating the Rototek or Multireg 99 (Fig. 3). Adjust the chemical
quantity by using the cursor +/- (Fig. 4). When you have finished working, remove kit “A” from
the chemical port and reinsert the plug (Fig. 5).
