English

- 24 -

FIG. 12

ADVICE ON USING DETERGENTS

Warning

This cleaner has been designed for use with the detergents

supplied or recommended by the manufacturer.

The  use  of  other  detergents  or  chemicals  may  influence  the

safety of the cleaner.

1

)

 For environmental compatibility

, we recommend a reaso-

nable use of detergents, according to the instructions on the

pack.

2

) From the range of recommended products, choose the

one most suited to the washing job to be done and dilute it

with water according to the instructions on the pack or in the

catalogue of the detergents most suited for the type of hot or

cold water cleaner.

3

) Ask your dealer for the detergents catalogue.

Danger

During use with boiling water, "Steam Phase", keep away

from the openings for fumes discharge (risk of burning).

When you have finished using the "Steam Phase", turn the

thermostat knob "B" to position "0" (fig. 8) and let the ma

-

chine cool down for about  3 minutes with the gun turned on.

OPERATING PHASES FOR CORRECT CLEANING WITH

DETERGENTS.

1)

 Prepare the solution of detergent at the concentration

most suitable for the type of dirt and the surface that is to be

washed.

2)

 Start the cleaner, turn on the detergent tap, and spray the dirty

surface with the diluted product, working from bottom to top.

Let it react for a few minutes.

3)

 Rinse the whole surface well from top to bottom with hot or

cold water at high pressure.

4)

After use with detergent, rinse the high pressure water circuit

by operating the pump for one minute with the detergent tap

completely closed.

MAINTENANCE

ONLY THE OPERATIONS AUTHORIZED IN THIS IN-

STRUCTIONS MANUAL MAY BE CARRIED OUT BY THE

USER.

ALL OTHER OPERATIONS ARE FORBIDDEN.

Danger

For maintenance of the boiler, high pressure pump, the electrical

parts and all parts with a safety function, you must apply to our

Technical service centre.

The manufacturer is not liable in case of tampering, changes, in-

correct  repairs or maintenance carried out  on the machine  by a

third person not provided with the manufacturer’s authorization.

All documents pertaining to the repair and planned service

interventions, as  well as any certificates concerning the device

installation according to the laws in force (in compliance with the

provisions of the IEC 60364-1 standard) must be kept carefully

by the user, together with the Instructions Manual.

Periodically, at least once a year, have the safety devices and

the rated values checked at one of our technical service centres.

Particularly,  as for the hot water high pressure cleaner, which is

factory set, the exhaust system must be checked.

The rating done by the manufacturer determines a production of

exhaust gases with a CO content lower than 0,04% and a  smoke

content corresponding to a smoke point nr.2 Shell-Bacharach

according to the laws in force.

Danger

Disconnect the water cleaner from the mains electricity supply

via the omnipolar switch or by unplugging the plug from the

socket and close the water supply tap (see chapters on connec-

ting to the electricity and water mains

)

before carrying out any

maintenance jobs.  Once maintenance has been completed,

ensure that the closing panels have been correctly reassembled

and anchored with the screws provided before reconnecting the

cleaner to the mains.

Failure to do so may cause a risk of electric shock.

!

!

!

FIG. 11

USE OF THE DOUBLE LAN-

CE. (fig.11) (if available).

The double lance allows the

operator to select a low or high

pressure jet.  The pressure is

selected with the gun in pos.

1.  High pressure: pos. 2.  Low

pressure.

USING  STEAM.

Use the steam nozzle (supplied as an accessory).

Turn the thermostat knob “B” (fig. 8) to steam position to obtain

an increase in the temperature of the water at delivery.

At work temperatures higher than 95°C (203°F), the work

pressure must be < 32 bar (460 PSI).

REGULATING PRESSURE

AND USING STEAM.

This chapter concerns only

those models provided with

the “pressure regulating” de-

vice. The pressure regulator,

fig. 12, allows the operator to

adjust the working pressure.

When knob C is turned in

an anti-clockwise direction

(B) (minimum), the working

pressure is reduced.

!
