- 23 -

English

U S I N G   T H E   M U LT I R E G

ADJUSTABLE NOZZLE

(fig. 10)

Pressure must be selected

with the gun switched off.

Low pressure washing and

detergent suction.

Shift the nozzle towards the

gun.

Washing  at  high  pressure

with  a  concentrated  jet  of

water

Turn the nozzle in a clockwise

direction.

Washing  at  high  pressure

with  a  fan-shaped  jet  of

water

Turn the nozzle in an anti-

clockwise direction.

USE OF THE DOUBLE LAN-

CE  (fig. 11).

The double lance  allows the

operator to select a low or high

pressure jet.  The pressure is

selected with the gun in pos.

1.  High pressure: pos. 2.

Low pressure and detergent

intake: pos. 3.

REGULATING PRESSURE

This chapter concerns only

those models provided with

the  “pressure  regulating”

device.

 The pressure regula-

tor, fig. 12, allows the operator

to adjust the working pressu-

re.  When knob C is turned

in an anti-clockwise direction

(B) (minimum), the working

pressure is reduced.

ADVICE ON USING DETERGENTS

Warning

This cleaner has been designed for use with the detergents

supplied or recommended by the manufacturer.

The  use  of  other  detergents  or  chemicals  may  influence  the

safety of the cleaner.

1

) For environmental compatibility, we recommend a reaso-

nable  use  of  detergents  (fig.9),  according  to  the  instructions

on the pack.

2

) From the range of recommended products, choose the

one most suited to the washing job to be done and dilute it

with water according to the instructions on the pack or in the

catalogue of the detergents most suited for the type of hot or

cold water cleaner.

3

) Ask your dealer for the detergents catalogue.

OPERATING PHASES FOR CORRECT CLEANING WITH

DETERGENTS

1

) Prepare the solution of detergent at the concentration most

suitable for the type of dirt and the surface that is to be washed.

2

) Start the cleaner, turn on the detergent tap (fig. 6B), switch

on the detergent suction control on the lance and spray the dirty

surface with the diluted product, working from bottom to top.

Let it react for a few minutes.

3

) Rinse the whole surface well from top to bottom at high

pressure.

4

)

After use with detergent, rinse the high pressure water circuit

by operating the pump for one minute with the detergent tap

completely closed.

 (fig. 8).

FIG.10

FIG.11

FIG.12

!
