- 22 -

English

5)

  Turn off the water supply

tap (fig. 4A).

Warning

- If the water cleaner is left,

even temporarily, turn it off by

using the omnipolar switch or

by unplugging the plug from

the socket.

- Water cleaners with the

“Total Stop” device should be

considered  as  off  when  the

omnipolar switch is in the “O”

position or the plug is unplug-

ged from the socket.

- When the water cleaner is not

used, close the safety device

on the handle (fig. 9).

- Dry use of the water cleaner

causes serious damage to

pump gaskets.

USING

THE CLEANER

CONTROL PANEL

A

 - On/off switch

B

 - Detergent control tap.

STARTING THE CLEANER

1

) Turn on the water supply

tap (fig. 4A).

2

) Connect the water cleaner

to the mains electricity supply

via the omnipolar switch or

by plugging the plug into the

socket.

3

) Start the cleaner by turning

the selector switch to pos. 1

(fig. 6A).

Warning

The high pressure water jet

generates a reaction force in

the lance. Keep a firm grip on

the lance handle.

4

) Press the trigger on the gun

and begin washing.

Warning

In water cleaners with the

“Total Stop” system, the motor

starts and stops when the

lever on the lance handle is

actioned or released.

Danger

Do not block the handle lever

in the delivery position.

IMPORTANT!

To  eliminate  any  impurities

or air bubbles from the wa-

ter circuit we advise starting

the cleaner for the first time

without the lance and letting

the  water  run  out  for  a  few

seconds.

Impurities  could  block  the

nozzle and cause malfunc-

tion (Fig. 7).

FIG. 8

FIG. 6

FIG. 7

FIG. 9

!

!

!

!

!

!

A

B

USING THE ACCESSORIES.

The high pressure washer has a nozzle with a flat  angle jet for

cleaning large surfaces.

Warning

Aim the jet from a certain distance to avoid damage caused by

the high pressure.

ROTARY HEAD (optional accessory)

The high pressure washer can be fitted with a head with rotary

nozzle to clean the most stubborn dirt.

Danger:

Aim the jet from a certain distance to avoid damage caused by

the high pressure.

Do not aim the jet at people, animals or electrical sockets.

STOPPING THE CLEANER

1)

After use with detergent, rinse the high pressure water

circuit by operating the pump for one minute with the detergent

tap completely closed.

 (fig. 8).

2)

  Stop the cleaner by turning the selector switch to pos. "0"

(fig. 6A).

3)

  Discharge the pressure from the H.P. hose by pressing the

trigger on the gun (fig. 5A).

4)

  Disconnect the water cleaner from the mains electricity

supply via the omnipolar switch or by unplugging the plug from

the socket.
