i
<變數 1>
Regulatory Notices
FCC Compliance Statement
Note: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
∙
Reorient or relocate the receiving antenna.
∙
Increase the separation between the
equipment and receiver.
∙
Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
∙
Consult the dealer or an experienced radio/TV
technician for help.
Caution: Changes or modifications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
Tested to comply with FCC standards
FOR HOME OR OFFICE USE
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.
CE Conformity
Products bearing the CE marking
comply with one or more of the
following EU Directives as may be
applicable:
RED 2014/53/EU; Low Voltage Directive 2014/35/
EU; EMC Directive 2014/30/EU; RoHS Directive
2011/65/EU.
Compliance with these directives is assessed
using applicable European Harmonized
Standards. The point of contact for regulatory
matters is MSI, MSI-NL Eindhoven 5706 5692
ER Son.
C-Tick Compliance
KC인증서
∙
Z590-A PRO
상호: (주)엠에스아이코리아
제품명: 메인보드
모델명:
10-7D09
제조년월: 2021년
제조자 및 제조국가: MSI/중국
∙
Z590 PRO WIFI
상호: (주)엠에스아이코리아
제품명: 메인보드
모델명:
Z590PW
제조년월: 2021년
제조자 및 제조국가: MSI/중국
クラスB情報技術装置
この装置は、クラスB情報技術装置です。
この装置は、家庭環境で使用することを
目的としていますが、この装置がラジオ
やテレビジョン受信機に近接して使用されると、受
信障害を引き起こすことがあります。取扱説明書に
従って正しい取り扱いをして下さい。
VCCI-B
Battery Information
European Union:
Batteries, battery packs, and
accumulators should not be
disposed of as unsorted household
waste. Please use the public
collection system to return, recycle,
or treat them in compliance with the
local regulations.
Taiwan:
廢電池請回收
For better environmental protection,
waste batteries should be collected
separately for recycling or special
disposal.
California, USA:
The button cell battery may contain
perchlorate material and requires
special handling when recycled or
disposed of in California.
For further information please visit:
http://www.dtsc.ca.gov/hazardouswaste/
perchlorate/
CAUTION: There is a risk of explosion, if battery
is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Regulatory Notices
R-R-MSI-10-7D09
R-R-MSI-Z590PW
Содержание
- 115 Безопасное использование продукции
- 116 Технические характеристики
- 122 Задняя панель портов ввода/ вывода; Таблица состояний индикатора порта LAN; Конфигурация портов Аудио
- 123 Компоненты материнской платы
- 125 Слоты DIMM; Рекомендации по установке модулей памяти
- 127 JAUD1: Разъем аудио передней панели
- 129 питания
- 131 JTBT1: Разъем для установки карты расширения
- 132 JTPM1: Разъем модуля ТРМ
- 133 JCI1: Разъем датчика открытия корпуса; Использование датчика открытия корпуса; JCOM1: Разъем последовательного порта
- 134 Сброс настроек BIOS до значений по умолчанию
- 135 Индикаторы отладки EZ; JRGB1: Разъем RGB LED
- 136 Установка ОС, драйверов и MSI Center; Установка Windows® 10; Установка драйверов; Инструкции по использованию MSI Center
- 137 Преимущества UEFI
- 138 Вход в настройки BIOS; Функциональные клавиши; Инструкции по настройке BIOS
- 139 Сброс BIOS; Обновление BIOS при помощи M-FLASH
- 140 Обновление BIOS при помощи MSI Center
- 226 ii; WEEE (Waste Electrical and
