GA-MA790GP-UD3H Motherboard

- 82 -

Figure 1

Step 2:
Then a controller menu similar to Figure 2 below will appear. Select

AMD AHCI Compatible RAID

Controller-x86 platform

 and press <Enter>. On the next screen, press <Enter> to continue the driver

installation. After the driver installation, you can proceed with the Windows XP installation.

Windows Setup

Press F6 if you need to install a third party SCSI or RAID driver.

5-1-3 Installing the SATA RAID/AHCI Driver and Operating System

With the SATA RAID/AHCI driver diskette and correct BIOS settings, you are ready to install Windows
Vista/XP onto your hard drive(s). The followings are examples of Windows XP and Vista installation.

A. Installing Windows XP

Step 1:
Restart your system to boot from the Windows XP setup disk and press <F6>

as soon as you see the message

"Press F6 if you need to install a 3rd party SCSI or RAID driver" (Figure 1). A screen will then appear asking you
to specify additional device. Insert the floppy disk containing the SATA RAID/AHCI driver and press <S>.

Figure 2

Windows Setup

 ENTER=Select   F3=Exit

You have chosen to configure a SCSI Adapter for use with Windows,
using a device support disk provided by an adapter manufacturer.

Select the SCSI Adapter you want from the following list, or press ESC
to return to the previous screen.

AMD AHCI Compatible RAID Controller-x86 platform
AMD AHCI Compatible RAID Controller-x64 platform

Step 3:
On the next screen, press <Enter> to continue the driver installation. After the driver installation, you can
proceed with the Windows XP installation.
