- 4 -
Table of Contents
Box Contents ................................................................................................................. 6
Optional Items ................................................................................................................. 6
GA-MA790GP-UD3H Motherboard Layout .................................................................... 7
Block Diagram ................................................................................................................ 8
Chapter 1 Hardware Installation .................................................................................... 9
1-1
Installation Precautions ..................................................................................... 9
1-2
Product Specifications .................................................................................... 10
1-3
Installing the CPU and CPU Cooler .............................................................. 13
1-3-1
Installing the CPU ................................................................................................ 13
1-3-2
Installing the CPU Cooler ................................................................................... 15
1-4
Installing the Memory ..................................................................................... 16
1-4-1
Dual Channel Memory Configuration ................................................................ 16
1-4-2
Installing a Memory ............................................................................................. 17
1-5
Installing an Expansion Card ......................................................................... 18
1-6
Enabling the ATI Hybrid CrossFireX
TM
Function ............................................ 19
1-7
Setup of ATI CrossFireX
TM
Configuration ........................................................ 20
1-8
Back Panel Connectors ................................................................................. 21
1-9
Internal Connectors ........................................................................................ 24
Chapter 2 BIOS Setup ................................................................................................. 35
2-1
Startup Screen ................................................................................................ 36
2-2
The Main Menu .............................................................................................. 37
2-3
MB Intelligent Tweaker(M.I.T.) ....................................................................... 39
2-4
Standard CMOS Features ............................................................................. 44
2-5
Advanced BIOS Features .............................................................................. 46
2-6
Integrated Peripherals ..................................................................................... 49
2-7
Power Management Setup ............................................................................. 52
2-8
PnP/PCI Configurations ................................................................................. 54
2-9
PC Health Status ........................................................................................... 55
2-10 Load Fail-Safe Defaults ................................................................................... 57
2-11 Load Optimized Defaults ................................................................................. 57
2-12 Set Supervisor/User Password ..................................................................... 58
