Hardware Installation

- 8 -

1-2  Product Specifications

CPU

AM3+ Socket:

Š

-   AMD AM3+ FX processors

*   You must install an external graphics card if you want to install Windows XP on your

AM3+ CPU-based system.

-   AMD AM3 Phenom

™

 II processors/AMD Athlon

™

 II processors

(Go to GIGABYTE's website for the latest CPU support list.)

Hyper Transport
Bus

2000 MT/s

Š

Chipset

NVIDIA

Š

®

 GeForce 7025/nForce 630a

Memory

2 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory

Š

*   Due to Windows 32-bit operating system limitation, when more than 4 GB of physical

memory is installed, the actual memory size displayed will be less than 4 GB.

Dual channel memory architecture

Š

Support for DDR3 1600/1333/1066/800 MHz memory modules

Š

 (Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)

Onboard
Graphics

Chipset:

Š

-   1 x D-Sub port

Audio

Realtek ALC888B/889 codec

Š

High Definition Audio

Š

2/4/5.1/7.1-channel

Š

*   To configure 7.1-channel audio, you have to use an HD front panel audio module

and enable the multi-channel audio feature through the audio driver.

LAN

1 x Realtek RTL8211CL chip (10/100/1000 Mbit)

Š

Expansion Slots

Š

1 x PCI Express x16 slot, running at x16
2 x PCI Express x1 slots

Š

1 x PCI slot

Š

Storage Interface

Chipset:

Š

-   4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices

-   Support for RAID 0, RAID 1, RAID 5, RAID 10, and JBOD

USB

Chipset:

Š

-   Up  to  10  USB  2.0/1.1  ports  (4  ports  on  the  back  panel,  6  ports  available

through the internal USB headers)

Internal

Connectors

1 x 24-pin ATX main power connector

Š

1 x 4-pin ATX 12V power connector

Š

4 x SATA 3Gb/s connectors

Š

1 x CPU fan header

Š

1 x system fan header

Š

1 x front panel header

Š

1 x front panel audio header

Š

3 x USB 2.0/1.1 headers

Š

1 x parallel port connector

Š

1 x clearing CMOS jumper

Š
