GA-8VM800PMD-775 Motherboard
- 70 -
English
After selecting a RAID mode, you must decide whether you want the RAID array to be configured
automatically or manually.
Auto Setup
allows BIOS to assign the hard drives and create arrays automatically, but it does not
duplicate the mirroring drives even if user selects
Create and duplicate for RAID 1
. It is recom-
mended all hard drives are new ones when you want to create an array.
Select Disk Drives
lets users select the array drives by their requirements. Select the
Select Disk
Drives
item and press ENTER, use the ARROW keys to select the target hard drive(s). The selected
hard drives will be marked with an asterisk (Figure 8).
Next, use the ARROW keys to select
Start Create Process
and press ENTER. The prompt "
The data
on the selected disks will be destroied. Continue? (Y/N)"
will appear. Press Y to confirm or N to
abort.
Important
All existing contents in the hard drive will be destroyed after the array creation.
Figure 8
VIA Tech. VT8237 SATA RAID BIOS Ver 2.31
Channel
Drive Name
Array Name
Mode
Size(GB)
Status
[*]Serial_Ch0 Master ST3120026AS
SATA
111.79
Stripe0
[*]Serial_Ch1 Master ST3120026AS
SATA
111.79
Stripe1
Create a RAID array with
the hard disks attached to
VIA RAID controller
F1
: View Array/disk Status
,
: Move to next item
Enter : Confirm the selection
ESC
: Exit
Auto Setup For Performance
Array Mode RAID 0 (Striping)
Select Disk Drives
Block Size 64K
Start Create Process
If you select to create RAID 0 array manually, you can specify the block size. Use the UP or DOWN
ARROW keys to select
Block Size
and press ENTER. Select the block size from the popup menu. The
block size can be set between 4KB to 64KB (Figure 9).
Figure 9
VIA Tech. VT8237 SATA RAID BIOS Ver 2.31
Channel
Drive Name
Array Name
Mode
Size(GB)
Status
[*]Serial_Ch0 Master ST3120026AS
SATA
111.79
Stripe0
[*]Serial_Ch1 Master ST3120026AS
SATA
111.79
Stripe1
Create a RAID array with
the hard disks attached to
VIA RAID controller
F1
: View Array/disk Status
,
: Move to next item
Enter : Confirm the selection
ESC
: Exit
Auto Setup For Performance
Array Mode RAID 0 (Striping)
Select Disk Drives
Block Size 64K
Start Create Process
4K
8K
16K
32K
64K
