Hardware Installation
- 8 -
1-2 Product Specifications
CPU
AM3+ Socket:
- AMD AM3+ processor
- AMD AM3 Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport
Bus
5200 MT/s
Chipset
North Bridge: AMD 760G
South Bridge: AMD SB710
Memory
2 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture
Support for DDR3 1333+ (O.C.)/1066/800 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
North Bridge:
- 1 x D-Sub port
- 1 x DVI-D port, supporting a maximum resolution of 1920x1200
* The DVI-D port does not support D-Sub connection by adapter.
Audio
Realtek ALC889 codec
High Definition Audio
2/4/5.1/7.1-channel
* To enable 7.1-channel audio, you have to use an HD front panel audio module and
enable the multi-channel audio feature through the audio driver.
LAN
1 x Realtek RTL8111E chip (10/100/1000 Mbit)
Expansion Slots
1 x PCI Express x16 slot, running at x16
1
x PCI Express x1 slot
(All PCI Express slots conform to the PCI Express 2.0 standard.)
1 x PCI slot
Storage Interface
South Bridge:
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 10, and JBOD
USB
South Bridge:
- Up to 6 USB 2.0/1.1 ports (2 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
j
- Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
k
Etron EJ168 chip:
j
- Up to 2 USB 3.0/2.0 ports on the back panel
j
Only for GA-78LMT-USB3.
k
Only for GA-78LMT-S2P.
