BIOS Setup
PCI1 IRQ Assignment
Auto
BIOS auto-assigns IRQ to the first PCI slot. (Default)
3,4,5,7,9,10,11,12,14,15
Assigns IRQ 3,4,5,7,9,10,11,12,14,15 to the first PCI slot.
ErP Support
Determines whether to let the system consume less than 1W power in S5 (shutdown) state. (Default:
Disabled)
Note: When this item is set to
Enabled
, the following four functions will become unavailable:
PME event wake up, power on by mouse, power on by keyboard, and wake on LAN.
2-8 PnP/PCI Configurations
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
PnP/PCI Configurations
PCI1 IRQ Assignment
[Auto]
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
2-9 PC Health Status
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
PC Health Status
Hardware Thermal Control
[Enabled]
Reset Case Open Status
[Disabled]
Case Opened
No
Vcore
1.280V
DDR3 1.5V
1.616V
+3.3V
3.296V
+12V
12.365V
Current System Temperature
41
o
C
Current CPU Temperature
35
o
C
Current CPU FAN Speed
1264 RPM
Current SYSTEM FAN Speed
0 RPM
CPU Warning Temperature
[Disabled]
CPU FAN Fail Warning
[Disabled]
SYSTEM FAN Fail Warning
[Disabled]
CPU Smart FAN Control
[Enabled]
CPU Smart FAN Mode
[Auto]
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
Hardware Thermal Control
Enables or disables the CPU overheating protection function. When enabled, the CPU core voltage and
ratio will be reduced when the CPU is overheated. (Default: Enabled)
Reset Case Open Status
Keeps or clears the record of previous chassis intrusion status.
Enabled
clears the record of previous
chassis intrusion status and the
Case Opened
field will show "No" at next boot. (Default: Disabled)
Case Opened
Displays the detection status of the chassis intrusion detection device attached to the motherboard CI
header. If the system chassis cover is removed, this field will show "Yes", otherwise it will show "No". To
clear the chassis intrusion status record, set
Reset Case Open Status
to
Enabled
, save the settings to
the CMOS, and then restart your system.
