BIOS Setup
- 22 -
2-3 MB Intelligent Tweaker(M.I.T.)
•
Whether the system will work stably with the overclock/overvoltage settings you made is depen-
dent on your overall system configurations. Incorrectly doing overclock/overvoltage may result in
damage to CPU, chipset, or memory and reduce the useful life of these components. This page is
for advanced users only and we recommend you not to alter the default settings to prevent system
instability or other unexpected results. (Inadequately altering the settings may result in system's
failure to boot. If this occurs, clear the CMOS values and reset the board to default values.)
•
When the
System Voltage Optimized
item blinks in red, it is recommended that you set the
System Voltage Control
item to
Auto
to optimize the system voltage settings.
(Note) This item is present only when you install a CPU that supports this feature.
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
MB Intelligent Tweaker(M.I.T.)
IGX Configuration
[Press Enter]
CPU Clock Ratio
[Auto]
2800Mhz
CPU NorthBridge Freq.
[Auto]
2000Mhz
Core Performance Boost
(Note)
[Enabled]
CPB Ratio
(Note)
[Auto]
3100Mhz
Turbo CPB
(Note)
[Disabled]
CPU Host Clock Control
[Auto]
x CPU Frequency(MHz)
200
PCIE Clock(MHz)
[Auto]
HT Link Width
[Auto]
HT Link Frequency
[Auto]
2000Mhz
Set Memory Clock
[Auto]
x Memory Clock
x4.00
800Mhz
DRAM Configuration
[Press Enter]
******** System Voltage Optimized ********
System Voltage Control
[Auto]
x DDR3 Voltage control
Auto
x NorthBridge Volt Control
Auto
x SouthBridge Volt Control
Auto
x CPU NB VID Control
Auto
x CPU Voltage Control
Auto
Normal CPU Vcore
1.2750V
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
IGX Configuration
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
Internal Graphics Mode
[UMA]
UMA Frame Buffer Size
[Auto]
x Surround View
Disabled
VGA Core Clock control
[Auto]
x VGA Core Clock(MHz)
350
IGX Configuration
Internal Graphics Mode
Allows you to determine whether to allocate system memory for the onboard graphics controller.
Disabled
Disables the onboard graphics controller.
UMA
Allocates memory for the onboard graphics controller from the system memory. (Default)
UMA Frame Buffer Size
Frame buffer size is the total amount of system memory allocated solely for the onboard graphics con-
troller. MS-DOS, for example, will use only this memory for display. Options are: Auto (default), 128MB,
256MB, 512MB.
