- 23 -
BIOS Setup
Surround View
Enables or disables the Surround View function. This option is configurable only when
Init Display First
under
Advanced BIOS Features
is set to
PEG
and an ATI graphics card is installed. (Default: Disabled)
VGA Core Clock control
Allows you to determine whether to manually set the VGA Core clock. (Default: Auto)
VGA Core Clock(MHz)
Allows you to manually set the VGA Core clock. The adjustable range is from 200 MHz to 2000 MHz.
This item is configurable only when the
VGA Core Clock control
option is set to
Manual
.
CPU Clock Ratio
Allows you to alter the clock ratio for the installed CPU. The adjustable range is dependent on the CPU
being used.
CPU NorthBridge Freq.
Allows you to alter the North Bridge controller frequency for the installed CPU. The adjustable range is
dependent on the CPU being used.
Core Performance Boost
(Note)
Allows you to determine whether to enable the Core Performance Boost (CPB) technology, a CPU
performance-boost technology. (Default: Enabled)
CPB Ratio
(Note)
Allows you alter the ratio for the CPB. The adjustable range is dependent on the CPU being installed.
(Default: Auto)
Turbo CPB
(Note)
Allows you to determine whether to improve CPU performance. (Default: Disabled)
CPU Host Clock Control
Enables or disables the control of CPU host clock.
Auto
(default) allows the BIOS to automatically adjust
the CPU host frequency.
Manual
allows the
CPU Frequency (MHz)
item below to be configurable.
Note: If your system fails to boot after overclocking, please wait for 20 seconds to allow for automated
system reboot, or clear the CMOS values to reset the board to default values.
CPU Frequency(MHz)
Allows you to manually set the CPU host frequency. The adjustable range is from 200 MHz to 500 MHz.
This option is configurable only when
CPU Host Clock Control
is set to
Manual
.
Important
It is highly
recommended that the CPU frequency be set in accordance with the CPU specifications.
PCIE Clock(MHz)
Allows you to manually set the PCIe clock frequency. The adjustable range is from 100 MHz to 150 MHz.
Auto
sets the PCIe clock frequency to standard 100 MHz. (Default: Auto)
HT Link Width
Allows you to manually set the width for the HT Link between the CPU and chipset.
Auto
BIOS will automatically adjust the HT Link Width. (Default)
8 bit
Sets HT Link Width to 8 bit.
16 bit
Sets HT Link Width to 16 bit.
HT Link Frequency
Allows you to manually set the frequency for the HT Link between the CPU and chipset.
Auto
BIOS will automatically adjust the HT Link Frequency. (Default)
x1~x10
Sets HT Link Frequency to x1~x10 (200 MHz~2.0 GHz).
Set Memory Clock
Determines whether to manually set the memory clock.
Auto
lets BIOS automatically set the memory
clock as required.
Manual
allows the memory clock control item below to be configurable. (Default: Auto)
(Note) This item is present only when you install a CPU that supports this feature.
