Hardware Installation
- 10 -
1-2 Product Specifications
CPU
Support for an Intel
®
Core
™
i7 series processor in the LGA1366 package
( Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
QPI
4.8GT/s, 6.4GT/s
Chipset
North Bridge: Intel
®
X58 Express Chipset
South Bridge: Intel
®
ICH10R
Memory
6 x 1.5V DDR3 DIMM sockets supporting up to 24 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
3/Dual channel memory architecture
Support for DDR3 2200/1333/1066/800 MHz memory modules
Support for non-ECC memory modules
Support for Extreme Memory Profile (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio
1 x Creative CA20K2 chip
Support for Dolby
®
Digital Live and DTS
™
Connect
Support for X-Fi Xtreme Fidelity
®
and EAX
®
Advanced HD
™
5.0 technologies
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF
Out
LAN
1 x Bigfoot Killer E2100 chip (10/100/1000 Mbit)
1 x Marvell 88E1118R phy
Expansion Slots
2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
* For optimum performance, if only one PCI Express graphics card is to be installed, be
sure to install it in the PCIEX16_1 slot; if you are installing two PCI Express graphics
cards, it is recommended that you install them in the PCIEX16_1 and PCIEX16_2
slots.
2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)
* The PCIEX8_1 slot shares bandwidth with the PCIEX16_1 slot and the PCIEX8_2
slot with PCIEX16_2. The PCIEX16_1/PCIEX16_2 slot will operate at up to x8 mode
when the PCIEX8_1/PCIEX8_2 is populated.
(The PCIEX16_1, PCIEX16_2, PCIEX8_1, and PCIEX8_2 slots conform to PCI
Express 2.0 standard.)
2 x PCI Express x1 slots
1 x PCI slot
Multi-Graphics
Technology
Support for 3-Way/2-Way NVIDIA SLI technology and 4-Way/3-Way/2-Way ATI
CrossFireX™ technology
Storage Interface
South Bridge:
- 6 x SATA 3Gb/s connectors (SATA2_0~SATA2_5) supporting up to 6 SATA
3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10
Marvell 88SE9182:
- 2 x SATA 6Gb/s connectors (GSATA3_6, GSATA3_7) supporting up to 2
SATA 6Gb/s devices
- Support for SATA RAID 0 and RAID 1
