4
GETTING STARTED
Set the clock
1
Press the volume knob to enter
[FUNCTION]
.
2
Turn the volume knob to select
[SETTINGS]
, then press the knob.
3
Turn the volume knob to select
[CLOCK]
, then press the knob.
4
Press the volume knob to select
[CLOCK ADJ]
.
5
Turn the volume knob to adjust the hour, then press the knob.
6
Turn the volume knob to adjust the minute, then press the knob.
Press
4
/
¢
to move between the hour and minute adjustment.
7
Press and hold
to exit.
(or)
Press and hold
DISP
to enter clock adjustment mode directly while
in clock display screen.
Then, perform steps
5
and
6
above to set the clock.
1
Set the initial settings
1
Press
SRC
to enter
[STANDBY]
.
2
Press the volume knob to enter
[FUNCTION]
.
3
Turn the volume knob to select
[INITIAL SET]
, then press the knob.
4
Turn the volume knob to make a selection (see the table below), then press
the knob.
5
Press and hold
to exit.
• To return to the previous hierarchy, press
.
Default:
XX
PRESET TYPE
NORM
: Memorizes one station for each preset button in each band (FM1/ FM2/ FM3/
MW/ LW). ;
MIX
: Memorizes one station for each preset button regardless of the
selected band.
KEY BEEP
ON
: Activates the keypress tone. ;
OFF
: Deactivates.
RUSSIAN SET
ON
: Folder name, file name, song title, artist name, album name are displayed in
Russian (if applicable). ;
OFF
: Cancels.
P-OFF WAIT
Sets the duration when the unit will automatically turns off (while in standby mode)
to save the battery.
–––
: Cancels ;
20M
: 20 minutes ;
40M
: 40 minutes ;
60M
: 60 minutes
BUILTIN AUX
ON
: Enables AUX in source selection. ;
OFF
: Disables.
(
➜
7)
CD READ
1
: Automatically distinguishes between audio file disc and music CD. ;
2
: Forces to play
as a music CD. No sound can be heard if an audio file disc is played.
SWITCH PRE
REAR
/
SUB-W
: Selects whether rear speakers or a subwoofer are connected to the
line out terminals on the rear (through an external amplifier).
SP SELECT
OFF
/
5/4
/
6 * 9/6
/
OEM
: Selects according to the speaker size (5 inches or 4 inches,
6×9 inches or 6 inches) or OEM speakers for optimum performance.
ACCOFF MODE
ACC1
: Disables CD ejection and power-on immediately after the ACC switch is turned
off. ;
ACC2
: Disables CD ejection and power-on for 30 minutes after the ACC switch is
turned off.
F/W UPDATE
F/W UP xx.xx
YES
: Starts upgrading the firmware. ;
NO
: Cancels (upgrading is not activated).
For details on how to update the firmware, see: www.kenwood.com/cs/ce/
2
