6

Installation/Connection

degree of output. During operation, this results
in a strong heat generation. Therefore no
cables or other parts may adjoin the device. If
their insulation melts, there is the risk of a short
circuit or fire.

•   Removing: Turn off the device. Remove

the front panel and place it into the protective
case. Clamp off the negative pole of the vehicle
battery for the duration of the disassembly. First
carefully remove the trim ring (5) of the unit, by
slightly pulling it upwards and then towards you.
Now unscrew the four screws as shown in (4).
Remove carefully the unit from the mounting
sleeve and disconnect all wires. Make sure that
no vehicle cable can cause a short circuit after
the device has been unplugged.

Detachable control panel

•   To attach the front panel, insert the upper

side of the panel first and make sure the
connection pins slide into the connection slots,
then press the lower part of the panel to the
unit until hear a click.

•   Slant the front panel down. Press the

release lock (in the bottom of the front panel)
upward to release the front panel, and then
take out the front panel by pulling it downwards
and then towards you from the bottom. Once
the front panel is removed, the back plate will
close automatically after a few seconds and
the panel status indicator will blink.

 The control panel can easily be

damaged by shocks. After removing it, place
it in a protective case and be careful not to
drop it or subject it to strong shocks. The rear
connector that connects the main unit and the
control panel is an extremely important part. Be
careful not to damage it by pressing on it with
fingernails, pens, screwdrivers, etc.

  If the control panel is dirty, wipe off the

dirt with soft, dry cloth only. And use a cotton
swab soaked in isopropyl alcohol to clean the
socket on the back of the control panel.

Anti-theft system

The front panel of this unit can be stored in

the included protective case when not in used
and carried away when you leave the vehicle
to deter theft.

Switch off the power of the unit. Detach the

front panel, then put it to the protective case
and take it with you.
