11

Operation

Remote controller (RC)

1

2

3
4
5
6
7
8

9

10

16

17

18
19
20
21
22
23
24
25
26
27
28

30

29

31

11
12
13
14

15

1. MODE button
2. POWER button
3. UP cursor button
4. BND/RDM button
5. ENTER button
6. LEFT cursor button
7. DOWN cursor button
8. EJECT button
9. PTY button
10. P.SCN/RPT button
11. SEEK-/

 button

12. AF button
13. OSD button

14.  /PBC button
15. Digit buttons
16.

 button

17. MUTE button
18. MENU button
19. SUB-T button
20. RIGHT cursor button
21. SETUP button
22. ANGLE button
23. INT button
24. VOL+ button
25. A-B/ZOOM button
26. SEL button
27. SEEK+/

 button

28. VOL- button
29. AUDIO/GOTO button
30. TILT button
31. DUAL button

Changing the battery

1. Press the catch and at the same time pull

out the battery tray.

2. Insert the 1 lithium battery, type CR2025

(3 V) battery with the stamped (+) mark facing
upward. Insert the battery tray into the remote
controller.

  •  Store the battery where children

cannot reach. If a child accidentally swallows
the battery, consult a doctor immediately.

•  Do not recharge, short, disassemble or

heat the battery or dispose it in a fire.

•  Do not expose or bring into contact the

battery with other metallic materials. Doing this
may cause the battery to give off heat, crack or
start a fire.

•  When throwing away or saving the battery,

wrap it in tape and insulate; otherwise, the
battery may give off heat, crack or start a fire.

•  Please direct the Remote controller to the

IR sensor of the front panel.
