Operation

Operation

General operations

Touch screen

Due to the touch screen, you can fulfill most

functions not only by pressing buttons but also
by touching the options you need.

Turning the unit on/off

Press any button (except REL button and

EJECT button) to switch the unit on. Press
and hold POWER button on the panel or PWR
button on the RC to turn off the power.

Reset the unit

Operating the unit for the first time or after

replacing the car battery, you must reset the
unit. Press reset button on the unit with a
pointed object (such as a ballpoint pen) to set
the unit to initial state.

  When some errors occur on the display,

you can also press reset button to resume to
normal, and it will erase the clock setting and
some memorized functions.

Volume control

Press VOL+/VOL- buttons on the RC or on

the unit to increase/decrease the sound level.

Setting the sound characteristics

Press SEL button to open the following menu:

1

2

3

4

1. Setting list. Touch a setting to select its

adjustment.

2. Adjustment buttons. Touch them to adjust

corresponding setting.

3. Adjustment slidebar. Touch to adjust a

setting.

4. Equalizer mode selection button. Touch to

go to the mode list.

You can also adjust Equalizer, Bass, Treble,

Balance and Fader by pressing the cursor
buttons on the RC.

Mute function

Press MUTE button on the RC or PWR

button on the unit to turn off the sound. Press
the button again or adjust volume to resume
the sound output.

Mode selection

•  Repeatedly press MODE button on the

RC or on the panel to select a mode: Radio =>
Disc => USB => SD => TV => AV-in.

•  In any mode touch right top corner of the

screen or press MENU button to display the
Main menu as follows:

In the menu, touch the item of the mode you

need to select the corresponding mode.

  The Disc, USB and SD modes are only

available when a disc, USB or SD/MMC card is
inserted into the unit.

Angle setting

Press repeatedly TILT button to adjust the

desired angle of the monitor.

  Please do not adjust the monitor tilt

manually, otherwise it can get damaged.

AV in jack

AV jack is intended to receive audio and video
