Loosen the edge guide locking screws (
12
).
•
Slide the edge guide bar into holes in the footplate (
5
), use the
scale to set required distance and fix by tightening the edge guide
locking screws (
12
) (
fig. I
).
Edge guide bar should be pointed downwards.
CUTTING
•
Put front part of the footplate (
5
) flat on the material that you plan
to cut.
•
Switch on the jigsaw and wait until it reaches its full set rotational
speed.
•
Move the jigsaw slowly and guide the blade along previously set
cutting line.
•
When cutting curved lines move the jigsaw very carefully.
Cut at a uniform rate, pay attention to avoid overloading the jigsaw.
Excessive pressure applied on the blade will suppress pendulum
action and will affect cutting efficiency unfavourably. Decrease or
switch off the pendulum action completely when cutting along
gently curved line.
When the jigsaw footplate does not rest on the processed material
with its whole surface but is lifted above, there is danger of
breaking the blade.
CUTTING WITH USE OF LASER
Laser device unit generates laser beam that projects line on the
material and shows how the material will be cut. Laser beam is used
for precision cutting.
•
Press the laser switch button (
13
) (laser unit will start to project
red line through the laser beam aperture (
14
)) (
fig. J
).
•
Position the footplate (
5
) on the material that you plan to cut. Use
the laser beam as a reference line.
•
Make the cut along the line. Switch the laser off when cutting is
finished.
Dust produced when cutting may reduce intensity of laser beam,
therefore it is necessary to occasionally clean the laser generator.
Never look directly at the source of the laser beam, never point
the laser beam at any person.
CUTTING A HOLE IN MATERIAL
•
Drill a hole in processed material with 10 mm diameter.
•
Put blade into the hole and start cutting from that spot.
RECOMMENDATIONS FOR PROPER JIGSAW USE
Cut at a steady rate, pay attention to avoid overloading the
power tool. Excessive pressure applied on the blade will suppress
pendulum action and will affect cutting efficiency unfavourably.
Decrease or switch off the pendulum action completely when
cutting along gently curved line.
If the jigsaw footplate does not move while rested against the
processed material, but is lifted instead, there is a danger of
breaking the blade.
METAL CUTTING / TYPES OF BLADES
Use appropriate blades with more teeth for cutting of metal.
For metal cutting use appropriate lubricant (e.g. cutting oil). Metal
cutting without lubrication leads to rapid wear of blade. The below
table gives the best choices for blade type:
Teeth per
inch
Blade length
Application range
24
80 mm
Soft steel, non-ferrous metals
14
Non-ferrous metals, plastics
9
Wood, plywood:
•
Use only appropriate and sharp blades.
•
Do not use blades with damaged shank.
•
Use appropriate blade types.
OPERATION AND MAINTENANCE
Unplug the power cord from mains socket before commencing
any activities related to installation, adjustment, repair or
maintenance.
•
Cleaning the device after each use is recommended.
•
Do not use water or any other liquid for cleaning.
•
Clean the tool with a dry cloth or blow with compressed air at low
pressure.
•
Do not use any cleaning agents or solvents, they may damage
plastic parts.
•
Clean ventilation holes in the motor casing regularly to prevent
device overheating.
•
Regular lubrication of guiding roller is recommended. A drop of oil
applied in this spot will prolong lifetime of the roller.
•
In case of power cord damage replace it with a cord with the same
specification. Entrust the repair to a qualified specialist or return
the tool to a service point.
•
In case of excessive commutator sparking, have the technical
condition of carbon brushes of the motor checked by a qualified
person.
•
Always store the tool in a dry place, beyond reach of children.
REPLACEMENT OF CARBON BRUSHES
Immediately replace worn out (shorter than 5 mm), burnt or
cracked motor carbon brushes. Always replace both carbon
brushes at a time.
Entrust replacement of carbon brushes only to a qualified person.
Only original parts should be used.
All defects should be repaired by service workshop authorized by
the manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Jigsaw
Parameter
Value
Supply voltage
230 V AC
Power supply frequency
50 Hz
Rated power
600 W
Blade stroke cycles (without load)
500-3000 min
-1
M a x i m u m
thickness of
cut material
Wood
65 mm
Metal
8 mm
Blade stroke length
15 mm
Laser class
2
Laser power
< 1mW
Laser wavelength
λ = 650 nm
Protection class
II
Weight 2,1
kg
Year of production
2018
NOISE AND VIBRATION DATA
Information regarding noise and vibration
The following levels of emitted noise, such as emitted acoustic
pressure Lp
A
and acoustic power level Lw
A
and measurement
uncertainty K have been given in the instruction manual as defined
in the EN 60745 standard.
The following vibration value (acceleration value) a
h
and
measurement uncertainty K have been determined as defined in the
EN 60745-2-11 standard.
