select the maximum stroke rate. Firmly hold the machine
against the workpiece and by tilting the machine, slowly
plunge the saw blade into the workpiece.

When the base plate

9

 fully lays on the workpiece, continue

sawing along the desired cutting line.

Parallel Guide with Circle Cutter (Accessory)

Parallel Cuts (see figure H): Loosen the locking screw

26

 and

slide the scale of the parallel guide through the lead

13

 in the

base plate. Set the desired cutting width as the scale value on
the inside edge of the base plate. Tighten the locking screw

26

.

Circular Cuts (see figure I): Set the locking screw

26

 to the

other side of the parallel guide. Slide the scale of the parallel
guide through the lead

13

 in the base plate. Drill a hole in the

workpiece centred in the section to be sawn. Insert the cen-
tring tip

28

 through the inside opening of the parallel guide

and into the drilled hole. Set the radius as the scale value on
the inside edge of the base plate. Tighten the locking screw

26

.

Coolant/Lubricant

When sawing metal, coolant/lubricant should be applied
alongside cutting line because of the material heating up.

Maintenance and Service

Maintenance and Cleaning



Before any work on the machine itself (e. g. mainte-

nance, tool change, etc.) as well as during transport

and storage, remove the battery from the power tool.

There is danger of injury when unintentionally actuating
the On/Off switch.



For safe and proper working, always keep the machine

and ventilation slots clean.

Clean the saw blade holder regularly. For this, remove the saw
blade from the machine and lightly tap out the machine on a
level surface.

Heavy contamination of the machine can lead to malfunc-
tions. Therefore, do not saw materials that produce a lot of
dust from below or overhead.

Lubricate the guide roller

10

 occasionally with a drop of oil.

Check the guide roller

10

 regularly. If worn, it must be re-

placed through an authorised Bosch after-sales service agent.

The plastic sliding shoe

12

 should be replaced when it is

worn.

After-sales Service and Application Service

Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:

www.bosch-pt.com

Bosch’s application service team will gladly answer questions
concerning our products and their accessories.

In all correspondence and spare parts order, please always in-
clude the 10-digit article number given on the type plate of
the machine.

Great Britain

Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: (0844) 7360109
Fax: (0844) 7360146
E-Mail: boschservicecentre@bosch.com

Ireland

Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: (01) 4666700
Fax: (01) 4666888

Australia, New Zealand and Pacific Islands

Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: (01300) 307044
Fax: (01300) 307045
Inside New Zealand:
Phone: (0800) 543353
Fax: (0800) 428570
Outside AU and NZ:
Phone: +61 3 95415555
www.bosch.com.au

Republic of South Africa
Customer service

Hotline: (011) 6519600

Gauteng – BSC Service Centre

35 Roper Street, New Centre
Johannesburg
Tel.: (011) 4939375
Fax: (011) 4930126
E-Mail: bsctools@icon.co.za

KZN – BSC Service Centre

Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: (031) 7012120
Fax: (031) 7012446
E-Mail: bsc.dur@za.bosch.com

Western Cape – BSC Service Centre

Democracy Way, Prosperity Park
Milnerton
Tel.: (021) 5512577
Fax: (021) 5513223
E-Mail: bsc@zsd.co.za
