 English |

15

Bosch Power Tools

1 609 92A 33H | (9.9.16)

11

SDS clamping lever for saw blade release

12

“PowerLight”

13

Contact protector

14

Handle (insulated gripping surface)

15

“PowerLight” button

16

Thumbwheel for stroke rate preselection

17

Button for charge-control indicator *

18

Battery charge-control indicator *

19

Stroke rod

20

Vacuum connection *

21

Vacuum hose *

22

Splinter guard

23

Steel sliding shoe *

24

Screw

25

Scale for mitre angle  (only GST 18 V-LI B)

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with another.
It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This may
significantly increase the exposure level over the total working
period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may signif-
icantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2009/125/EC (Regulation
1194/2012), 2011/65/EU, until 19 April 2016:
2004/108/EC, from 20 April 2016 on: 2014/30/EU,
2006/42/EC including their amendments and complies with
the following standards: EN 60745-1, EN 60745-2-11,
EN 50581.

Technical file (2006/42/EC) at:
Robert Bosch Power Tools GmbH, PT/ECS,
70538 Stuttgart, GERMANY

Cordless Jigsaw

GST 18 V-LI S GST 18 V-LI B

Article number

3 601 EA5 1.. 3 601 EA6 1..

Rated voltage

V=

18

18

Stroke rate at no
load n

0

min

-1

550 – 2 700

0 – 2 700

Stroke

mm

23

23

Cutting capacity, max.
– in  wood
– in  aluminium
– in non-alloy steel

mm
mm
mm

120

20

8

120

20

8

Bevel cuts (left/right),
max.

°

–

45

Weight according to
EPTA-Procedure
01:2014

1)

– minimum
– maximum

kg
kg

2.1
2.6

2.1
2.6

Permitted ambient
temperature
– during charging
– during operation

2)

and during storage

° C

° C

0 ... + 45

– 20 ... + 50

0 ... + 45

– 20 ... + 50

Recommended
batteries

GBA 18 V...

GBA 18 V... W

GBA 18 V...

GBA 18 V... W

Recommended
chargers

AL 18 ...

GAL 3680

GAL 18...W

AL 18 ...

GAL 3680

GAL 18...W

1) depending on the battery pack being used

2) Limited performance at temperatures < 0 ° C

GST

 18 V-

LI

 S

GST

 18 V-LI

 B

Sound emission values determined
according to EN 60745-2-11.

Typically the A-weighted noise levels
of the product are
Sound pressure level
Sound power level
Uncertainty K

Wear hearing protection!

dB(A)
dB(A)

dB

79
90

3

81
92

3

Vibration total values a

h

 (triax vector

sum) and uncertainty K determined
according to EN 60745-2-11:
Sawing chipboard:
a

h

K
Sawing sheet metal:
a

h

K

m/s

2

m/s

2

m/s

2

m/s

2

7.5
1.5

8

1.5

6

1.5

8.5
1.5
